Philips FW-C100/21 - MB Module Electrical Parts List

RESISTORS
4807 © 4822 051 20008 CHIP JUMPER 0805
4808 © 4822 051 20008 CHIP JUMPER 0805
4809 © 4822 051 20008 CHIP JUMPER 0805
4810 © 4822 051 20008 CHIP JUMPER 0805
4812 © 4822 051 20008 CHIP JUMPER 0805
4814 © 4822 051 20008 CHIP JUMPER 0805
4815 © 4822 051 20008 CHIP JUMPER 0805
4816 © 4822 051 20008 CHIP JUMPER 0805
4817 © 4822 051 20008 CHIP JUMPER 0805
4818 © 4822 051 20008 CHIP JUMPER 0805
4819 © 4822 051 20008 CHIP JUMPER 0805
4820 © 4822 051 20008 CHIP JUMPER 0805
4821 © 4822 051 20008 CHIP JUMPER 0805
4822 © 4822 051 20008 CHIP JUMPER 0805
4823 © 4822 051 20008 CHIP JUMPER 0805
4824 © 4822 051 20008 CHIP JUMPER 0805
4825 © 4822 051 20008 CHIP JUMPER 0805
4826 © 4822 051 20008 CHIP JUMPER 0805
4827 © 4822 051 20008 CHIP JUMPER 0805
4828 © 4822 051 20008 CHIP JUMPER 0805
4831 © 4822 051 20008 CHIP JUMPER 0805
4832 © 4822 051 20008 CHIP JUMPER 0805
4834 © 4822 051 20008 CHIP JUMPER 0805
4835 © 4822 051 20008 CHIP JUMPER 0805
4836 © 4822 051 20008 CHIP JUMPER 0805
4838 © 4822 051 20008 CHIP JUMPER 0805
4843 © 4822 051 20008 CHIP JUMPER 0805
4845 © 4822 051 20008 CHIP JUMPER 0805
4846 © 4822 051 20008 CHIP JUMPER 0805
4847 © 4822 051 20008 CHIP JUMPER 0805
4849 © 4822 051 20008 CHIP JUMPER 0805
4856 © 4822 051 20008 CHIP JUMPER 0805
4857 © 4822 051 20008 CHIP JUMPER 0805
4858 © 4822 051 20008 CHIP JUMPER 0805
4859 © 4822 051 20008 CHIP JUMPER 0805
4860 © 4822 051 20008 CHIP JUMPER 0805
4861 © 4822 051 20008 CHIP JUMPER 0805
4862 © 4822 051 20008 CHIP JUMPER 0805
4863 © 4822 051 20008 CHIP JUMPER 0805
4864 © 4822 051 20008 CHIP JUMPER 0805
4865 © 4822 051 20008 CHIP JUMPER 0805
4867 © 4822 051 20008 CHIP JUMPER 0805
4868 © 4822 051 20008 CHIP JUMPER 0805
4869 © 4822 051 20008 CHIP JUMPER 0805
4870 © 4822 051 20008 CHIP JUMPER 0805
4876 © 4822 051 20008 CHIP JUMPER 0805
4879 © 4822 051 20008 CHIP JUMPER 0805
4884 © 4822 051 20008 CHIP JUMPER 0805
4885 © 4822 051 20008 CHIP JUMPER 0805
4886 © 4822 051 20008 CHIP JUMPER 0805
4887 © 4822 051 20008 CHIP JUMPER 0805
4890 © 4822 051 20008 CHIP JUMPER 0805
4893 © 4822 051 20008 CHIP JUMPER 0805
4894 © 4822 051 20008 CHIP JUMPER 0805
4896 © 4822 051 20008 CHIP JUMPER 0805
4897 © 4822 051 20008 CHIP JUMPER 0805
COILS
1810 2422 543 01068 RESONATOR 8MHZ
1810 4822 242 73557 CERAMIC RES. 8,46MHz
5802 4822 156 31058 FILTER DIGITAL OUT
DIODES
6871 © 4822 130 11397 BAS316
6872 © 4822 130 11397 BAS316
6873 © 4822 130 11397 BAS316
6874 © 4822 130 11397 BAS316
6875 © 9340 548 52115 BZX284-C5V1
6877 © 9322 129 34685 BZX284-C3V9
6878 © 4822 130 11397 BAS316
6879 © 9322 129 34685 BZX284-C3V9
TRANSISTORS
7812 © 5322 130 60159 BC846B
7874 © 5322 130 60159 BC846B
7875 © 5322 130 60159 BC846B
INTEGRATED CIRCUITS
7801 © 9352 622 36118 TZA1025T/V2, HF-Amplifier
7805 © 4822 209 33165 TDA1308T/N1, OPAMP
7806 4822 209 62059 TCA0372DP1, Motor driver
7807 4822 209 62059 TCA0372DP1, Motor driver
7808 4822 209 62059 TCA0372DP1, Motor driver
7821 4822 209 62059 TCA0372DP1, Motor driver
7822 4822 209 62059 TCA0372DP1, Motor driver
7873 5322 209 11306 HEF4094BT, Shift register
7876 4822 209 16143 LC89170M, CD TEXT IC
7877 © 9352 642 17557 SAA7325H/M2B Signal processor CD10
ELECTRICAL PARTS LIST 3CDC-LC-MB MODULE
10A-7
SPR 00 0037
