Philips FW-C100/21 - Combi Board Electrical Parts List

SPR 00 0045
11-8 11-8
ELECTRICAL PARTS LIST - COMBI BOARD ELECTRICAL PARTS LIST - COMBI BOARD
MISCELLANEOUS
1201 4822 265 31015
!
Mains Socket
1201 4822 265 31016
!
Mains Socket /37
1202 4822 272 10269
!
Voltage Selector /21/21M
1205 4822 071 58001
!
Fuse T800mA 250V /21/21M
1206 4822 071 51602
!
Fuse T1.6A 250V
1206 4822 253 10128
!
Fuse T2A 250V /37
1207 4822 071 51602
!
Fuse T1.6A 250V
1207 4822 253 10128
!
Fuse T2A 250V /37
1208 4822 071 53151
!
Fuse T315mA 250V
1208 4822 252 51151
!
Fuse T315mA 250V /37
1209 4822 071 51602
!
Fuse T1.6A 250V /21/21M
1322 4822 267 31176 Loudspeaker Socket
1325 4822 265 11529 Headphone Socket
1431 4822 276 13775 Tact Switch
1432 4822 276 13775 Tact Switch
1433 4822 276 13775 Tact Switch
1434 4822 276 13775 Tact Switch
1435 4822 276 13775 Tact Switch
1507 4822 265 20553 Aux-in Socket
1508 2422 025 14526 Flex Socket 16pin Vert.
1509 4822 265 10981 Flex Socket 15pin Vert.
1510 2422 025 14518 Flex Socket 9pin Vert.
1517 4822 267 10731 Flex Socket 6pin Vert.
CAPACITORS
2220 5322 121 42386 100nF 5% 63V
2221 5322 121 42386 100nF 5% 63V
2222 4822 124 21913 1µF 20% 63V
2223 4822 124 21913 1µF 20% 63V
2224 4822 121 51399 47nF 10% 50V
2225 4822 124 11878 4700µF 16V
2226 4822 124 80144 220µF 20% 25V
2227 4822 124 40255 100µF 20% 63V
2228 4822 124 41751 47µF 20% 50V
2229 5322 121 42386 100nF 5% 63V
2243 4822 124 42367 3300µF 20% 35V
2245 4822 124 80144 220µF 20% 25V
2301 4822 126 11585 22nF +80/-20% 25V
2302 4822 126 11585 22nF +80/-20% 25V
2320 4822 126 12785 47nF 50V
2323 4822 124 21913 1µF 20% 63V
2324 4822 124 21913 1µF 20% 63V
2325 4822 122 33519 470pF 10% 50V
2326 4822 122 33519 470pF 10% 50V
2327 4822 124 40433 47µF 20% 25V
2328 4822 124 40433 47µF 20% 25V
2329 4822 121 51399 47nF 10% 50V
2330 4822 121 51399 47nF 10% 50V
2331 4822 124 81144 1000µF 20% 16V
2332 4822 124 81144 1000µF 20% 16V
2333 4822 121 51399 47nF 10% 50V
2334 4822 121 51399 47nF 10% 50V
2335 4822 126 11585 22nF +80/-20% 25V
2336 4822 126 11585 22nF +80/-20% 25V
2337 4822 124 40433 47µF 20% 25V
2338 4822 124 80144 220µF 20% 25V
2339 4822 124 40207 100µF 20% 25V
2340 4822 126 14316 680pF 10% 50V
2341 4822 122 33519 470pF 10% 50V except /37
2342 4822 124 40207 100µF 20% 25V
2346 4822 126 11585 22nF +80/-20% 25V
2346 4822 121 51387 10nF 20% 16V /37
2347 4822 126 14316 680pF 10% 50V
2348 4822 126 14316 680pF 10% 50V
2400 4822 122 33191 22pF 5% 50V
2401 4822 122 33191 22pF 5% 50V
2402 4822 122 10459 560pF 10% 50V
2404 4822 124 40433 47µF 20% 25V
2405 4822 126 11585 22nF +80/-20% 25V
2406 4822 126 11585 22nF +80/-20% 25V
2501 4822 122 33195 100pF 10% 50V
2502 4822 122 33195 100pF 10% 50V
2503 4822 124 40248 10µF 20% 63V
2504 4822 124 40248 10µF 20% 63V
2505 4822 124 81151 22µF 20% 50V
2507 4822 124 81151 22µF 20% 50V
2508 4822 124 21913 1µF 20% 63V
2509 4822 124 21913 1µF 20% 63V
2510 4822 122 33519 470pF 10% 50V
2511 4822 122 33519 470pF 10% 50V
2512 4822 122 33519 470pF 10% 50V
2513 4822 122 33519 470pF 10% 50V
2514 4822 121 51399 47nF 10% 50V
2515 4822 121 51399 47nF 10% 50V
2518 4822 122 33519 470pF 10% 50V
2519 4822 122 33519 470pF 10% 50V
2524 4822 122 33191 22pF 5% 50V
2525 4822 122 33191 22pF 5% 50V
2530 4822 122 33195 100pF 10% 50V
2531 4822 122 33195 100pF 10% 50V
2532 4822 126 14316 680pF 10% 50V
2533 4822 126 14316 680pF 10% 50V
2534 4822 126 12878 1,5nF 10% 16V
2535 4822 126 12878 1,5nF 10% 16V
2536 4822 124 80791 470µF 20% 16V
2537 4822 126 12882 100nF +80/-20% 50V
2538 4822 126 12882 100nF +80/-20% 50V
2539 4822 121 42476 33nF 10% 50V
2540 4822 121 42476 33nF 10% 50V
2541 4822 126 12785 47nF +80/-20% 50V
2542 4822 126 12785 47nF +80/-20% 50V
2545 4822 126 12882 100nF +80/-20% 50V
2546 4822 126 12882 100nF +80/-20% 50V
2547 4822 124 41584 100µF 20% 10V
2549 4822 124 40746 0,22µF 20% 63V
2550 4822 124 40746 0,22µF 20% 63V
2551 4822 124 21913 1µF 20% 63V
2552 4822 124 21913 1µF 20% 63V
2553 4822 126 12787 330pF 10% 50V
2554 4822 126 12787 330pF 10% 50V
2555 4822 126 12787 330pF 10% 50V
2556 4822 126 12787 330pF 10% 50V
2557 4822 126 12787 330pF 10% 50V
2558 4822 126 12787 330pF 10% 50V
2559 4822 124 21913 1µF 20% 63V
2560 4822 124 21913 1µF 20% 63V
2561 4822 122 33519 470pF 10% 50V except /37
2562 4822 122 33519 470pF 10% 50V except /37
2563 4822 122 33195 100pF 10% 50V
2564 4822 126 12787 330pF 10% 50V
2565 4822 126 12787 330pF 10% 50V
2566 4822 126 12882 100nF +80/-20% 50V
2567 4822 126 11585 22nF +80/-20% 25V
2572 4822 126 12882 100nF +80/-20% 50V
2575 4822 122 33848 47pF 5% 50V
2576 4822 122 33848 47pF 5% 50V
2577 4822 124 80791 470µF 20% 16V
2578 4822 124 40207 100µF 20% 25V
2580 4822 124 40248 10µF 20% 63V
2581 4822 124 80195 470µF 20% 10V
2589 4822 122 33519 470pF 10% 50V
2590 4822 126 14316 680pF 10% 50V
2591 4822 122 33848 47pF 5% 50V
2592 4822 122 33848 47pF 5% 50V
2593 4822 122 33848 47pF 5% 50V
2594 4822 122 33848 47pF 5% 50V
2597 4822 122 10573 56pF 5% 50V
2598 4822 122 10573 56pF 5% 50V
2598 4822 122 33848 47pF 5% 50V /37
2599 4822 126 14316 680pF 10% 50V
2600 4822 122 10466 220pF 10% 50V
2600 4822 126 14316 680pF 10% 50V /37
9313 4822 126 11585 22nF +80/-20% 25V
RESISTORS
3208 4822 053 21106 10M 5% 0,5W /37
3213 4822 050 11002 1k 1% 0,4W
3214 4822 050 24708 4R7 1% 0,6W
3242 4822 050 24708 4R7 1% 0,6W
3246 4822 116 52175 100R 5% 0,5W
3247 4822 116 52175 100R 5% 0,5W
3248 4822 116 52175 100R 5% 0,5W
3249 4822 116 52175 100R 5% 0,5W
3252 4822 050 11002 1k 1% 0,4W
3253 4822 050 24708 4R7 1% 0,6W
3256 4822 050 21003 10k 1% 0,6W
3257 4822 050 21003 10k 1% 0,6W
3258 4822 116 52283 4k7 5% 0,5W
3259 4822 050 21003 10k 1% 0,6W
3260 4822 116 83872 220R 5% 0,5W
3261 4822 116 52238 12k 5% 0,5W
3263 4822 050 21003 10k 1% 0,6W
3264 4822 116 52289 5k6 5% 0,5W
3265 4822 116 52257 22k 5% 0,5W
3266 4822 116 83872 220R 5% 0,5W
3268 4822 116 83872 220R 5% 0,5W
3269 4822 116 52256 2k2 5% 0,5W
3272 4822 116 52206 120R 5% 0,5W
3300 4822 116 52206 120R 5% 0,5W
3301 4822 116 52206 120R 5% 0,5W
3321 4822 050 21003 10k 1% 0,6W
3322 4822 050 21003 10k 1% 0,6W
3325 4822 116 52256 2k2 5% 0,5W
3326 4822 116 52256 2k2 5% 0,5W
3327 4822 116 52226 560R 5% 0,5W
3328 4822 116 52226 560R 5% 0,5W
3329 4822 116 52269 3k3 5% 0,5W
3330 4822 116 52269 3k3 5% 0,5W
3331 4822 052 10228
!
2R2 5% 0,33W
3332 4822 052 10228
!
2R2 5% 0,33W
3333 4822 052 10228
!
2R2 5% 0,33W
3334 4822 052 10228
!
2R2 5% 0,33W
3335 4822 116 52269 3k3 5% 0,5W
3336 4822 050 21003 10k 1% 0,6W
3337 4822 116 83882 39k 5% 0,5W
3341 4822 116 52256 2k2 5% 0,5W
3342 4822 116 83884 47k 5% 0,5W
3400 4822 116 52256 2k2 5% 0,5W
3401 4822 116 52256 2k2 5% 0,5W
3402 4822 116 52256 2k2 5% 0,5W
3403 4822 116 52256 2k2 5% 0,5W
3404 4822 116 52256 2k2 5% 0,5W
3405 4822 116 83883 470R 5% 0,5W
3406 4822 116 52256 2k2 5% 0,5W
3407 4822 116 52256 2k2 5% 0,5W
3408 4822 116 52176 10R 5% 0,5W
3409 4822 116 52289 5k6 5% 0,5W
3410 4822 116 52303 8k2 5% 0,5W
3411 4822 116 52175 100R 5% 0,5W
3412 4822 116 52175 100R 5% 0,5W
3413 4822 116 52175 100R 5% 0,5W
3453 4822 116 52207 1k2 5% 0,5W
3454 4822 116 52256 2k2 5% 0,5W
3455 4822 116 52276 3k9 5% 0,5W
3456 4822 116 52303 8k2 5% 0,5W
3501 4822 116 52297 68k 5% 0,5W
3502 4822 116 52297 68k 5% 0,5W
3509 4822 116 52297 68k 5% 0,5W
