Philips FW-C100/21 - Page 80

SPR 00 0049
12-2
12-2
MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT SCREW LISTS - MAIN UNIT
185 D3 x 25
198 D3 x 12
202 D3 x 12
205 D3 x 12
277 D3 x 12
278 D3 x 12
280 D3 x 12
282 D3 x 12
283 D3 x 16
284 M3 x 15
285 D3 x 16
286 D3 x 12
288 D3 x 12
289 D3 x 12
290 D3 x 12
293 D3 x 12
294 D2 x 8
297 D3 x 12
299 D3 x 12
101 3139 118 13520 Cabinet Front Assembly
105 3139 118 10440 Window CDC Control
106 3139 118 13230 Button Set CDC Select
107 3139 118 13210 Cover Tray CDC-LC
108 4822 454 13408 Badge Philips
124 3139 118 13290 Window Display
124 3139 118 13530 Window Display /37
131 3139 118 13540 Button Set Prog/Clock/DBB
132 3139 118 13550 Button Power On/Off
133 3139 118 13240 Button Set Source Select
135 3139 118 13560 Button Set Controls
144 3139 118 13570 Cover Ring Volume
145 3139 118 13580 Button DSC
146 3139 118 13590 Knob Volume Up/Down
153 3139 118 13250 Cover Controls
158 3139 118 13600 Cover Cassette Left
159 3139 118 13610 Cover Cassette Right
160 3139 114 71980 Lens Cassette Left
161 3139 114 71990 Lens Cassette Right
162-167 8240 009 27040 Rec/PB button set
168-172 8240 009 27050 Play button set
197 4822 529 10322 Damper Assembly
199 4822 492 70231 Spring Leaf
200 4822 443 10881 Door Cassette (Mech)
201 4822 492 42709 Spring Cassette Door
251 3139 114 69830 Cabinet Rear /21/22/30
251 3139 114 69840 Cabinet Rear /21M/34
251 3139 114 69850 Cabinet Rear /37
252 4822 462 40683 Foot Rubber SQ
255 4822 466 93148 Spacer 5mm
260 4822 492 11734 Spring IC
350 3139 118 78070 LS Box /37
350 3139 118 78080 LS Box /22/34
350 3139 118 78140 LS Box /21/21M/30
351 4822 303 50063 FM Aerial 75R
351 4822 320 11094 FM Antenna Wire /37
356 3139 228 86180 Rem Cont. RC282430/01
384 4822 303 50082 AM Frame Aerial
385 4822 321 10249
!
Mains Cord /21/21M/22/34
385 4822 321 10954
!
Mains Cord /30
385 4822 321 11466
!
Mains Cord /37
386 4822 263 21092
!
Adapter Plug /21
387 3139 115 20360 Instr. For Use /21/21M/30
387 3139 115 20280 Instruction For Use /22
387 3139 115 20330 Instruction For Use /34
387 3139 115 20160 Instruction For Use /37
1450 3139 110 34770 Flex Cable 15pin 22cm BD
1451 4822 320 12604 Flex Cable 9pin 22cm AD
1456 3139 110 34180 Flex Cable 16pin 22cm AD
1556 3139 110 34320 Flex Cable 6pin 40cm BD
5001 3139 118 32360
!
Mains Transfo. /21/21M
5001 3139 118 32370
!
Mains Transfo. /22/30/34
5001 3139 118 32350
!
Mains Transfo. /37
LOUDSPEAKER BOX BREAKDOWN
9965 000 06350 Speaker 4" 3R 5W Black
Note: Only the parts mentioned in this list are normal
service spare parts.
