10-4
CS 53 187
Lubrication Instructions
Grease
Grease inside grove
Grease on top of rib
Grease
Grease on top
of highest ring
Grease on four
rectangular surfaces
Grease inside
groves
Grease on slide
Grease on four
profile groves
CHASSIS
DRAWER
