PCS 103 544
12-2
12-2
MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT SCREW LISTS - MAIN UNIT
185 D3 x 12
211 D3 x 12
213 D3 x 12
214 D3 x 12
277 D3 x 12
278 D3 x 12
280 D3 x 12
281 D3 x 12
282 D3 x 12
283 D3 x 16
284 M3 x 15
285 D3 x 16
286 D3 x 12
288 D3 x 12
289 D3 x 12
290 D3 x 12
291 D3 x 12
293 D3 x 12
294 D2 x 8
295 D3 x 16
296 M3 x 6
297 D3 x 12
298 D3 x 12
299 D3 x 12
0101 313911810540 Cabinet Front
0105 313911810270 Window CDC Control
0106 313911789360 Button Set CDC Select
0107 313911810280 Cover Tray CDC2
0108 482245413408 Badge Philips
0124 313911810550 Window Display C38/21/21M
0124 313911811020 Window Display C38/22/34
0124 313911811850 Window Display C38/37
0124 313911810630 Window Display C39/21/21M
0124 313911811320 Window Display C39/30
0125 313911810920 Button Set DBB/VEC/DSC
0127 313911468340 Lightguide DSC ETF
0131 313911810590 Button Set Progam
0132 313911789410 Button Power On/Off
0133 313911469720 Button Set Source Select, Blue
0135 313911810760 Button Set Controls
0136 313911810310 Lightcap Source Select Blue
0137 313911810610 Button Incredible Sound
0139 313911468470 Button Clock-Timer
0139 313911468480 Button RDS/News/Clk /22/34
0143 313911468410 Cover Ring Jog ETF
0144 313911810330 Cover Ring Volume
0145 313911810600 Knob Jog Rotary 2
0146 313911810350 Knob Volume Rotary
0152 313911468030 Knob Karaoke /21/21M
0153 313911810580 Cover Control IS+K /21/21M
0153 313911810700 Cover Control IS /30/37
0153 313911810720 Cover Control IS+RDS /22/34
0158 313911810560 Cover Cassette Left 2
0159 313911810570 Cover Cassette Right 2
0160 313911468520 Lens Cassette Left 2
0161 313911468530 Lens Cassette Right 2
0197 482244310488 Door Cassette Right
0198 482244310487 Door Cassette Left
0199 482240210621 Push-Catch
0200 482252910322 Damper Assembly
0203 482249211344 Spring Compression
0204 482240211246 Bracket Right
0205 482240211245 Bracket Left
0208 482249211345 Spring Tension
0209 482249242787 Spring Cassette
0251 313911468260 Cab. Rear MIC C38/21
0251 313911468590 Cab. Rear NMI C38/21M/34
0251 313911468270 Cab. Rear MIH C38/22
0251 313911470450 Cab. Rear MIC C38/37
0251 313911468290 Cab. Rear Mtx MIC C39/21/30
0251 313911468600 Cab. Rear Mtx NMI C39/21M
0252 482246240683 Foot Rubber SQ
0255 482246693148 Spacer 5mm
0260 482249211734 Spring IC
0266 313911468040 Spacer Heatsink
0349 313911877360 Surround Box FW-C39 only
0350 313911877310 Loudspeaker Box /22/34/37
0350 313911877330 Loudspeaker Box /21/21M/30
0351 482230350063 FM Aerial 75R
0351 482232011094 FM Aerial 300R /37
0356 313922883620 Remote Control RC282426/01
0384 482230350082 AM Frame Aerial
0385 482232110249
!
Mains Cord /21/21M/22/34
0385 482232110954
!
Mains Cord /30
0385 482232111466
!
Mains Cord /37
0386 482226321092
!
Adapter Plug 6A 250V /21
0387 313911619400 Inst. For Use /21/21M/30
0387 313911619380 Instruction For Use /22
0387 313911619390 Instruction For Use /34
0387 313911619810 Instruction For Use /37
1451 482232012604 Flex Cable 9pin 22cm AD
1455 482232012654 Flex Cable 7pin 22cm AD
1456 313911034180 Flex Cable 16pin 22cm AD
1557 482232012663 Flex Cable 7pin 34cm BD
5001 313911832100
!
Power Transformer /21/21M
5001 313911832090
!
Power Transformer /22/30/34
5001 313911832080
!
Power Transformer /37
LEFT/RIGHT LOUDSPEAKER BOX BREAKDOWN
996500002232 Tweeter 2,5 6R 30W
996500002233 Woofer 5,25 6R 30W
996500002234 2,2µF 50V w/Wire Assembly
996500002235 Cloth Frame Assy /21/21M/30
996500002236 Cloth Frame Assy /22/34/37
SURROUND BOX BREAKDOWN
482224010374 Speaker 3 6R 7W
Note: Only the parts mentioned in this list are normal
service spare parts.
