8-4
8-4
ELECTRICAL PARTS - POWER BOARD
BD901 4822 130 10741 GBU6J
TR901 9940 000 01569 SW. MODEL TRANSFORMER
C902 9940 000 00932 COND SAFTY 0.47µF 275V 10%
TR902 9940 000 00959 SW. MODEL TRANSFORMER
C903 9940 000 00932 COND SAFTY 0.47µF 275V 10%
TR903 9940 000 00961 SW. MODEL TRANSFORMER
C909 9940 000 01085 COND DISC 0.001µF 1KV 20%
TVR901 9940 000 00962 PTC THERMISTOR 50A 561V
C913 9940 000 01086 COND DISC 0.01µF 1KV 20%
C915 9940 000 00934 COND SAFTY 0.0022µF 400V 20%
C916 9940 000 00934 COND SAFTY 0.0022µF 400V 20%
C917 9940 000 00934 COND SAFTY 0.0022µF 400V 20%
C918 9940 000 00935 COND SAFTY 0.001µF 250V 20%
C919 9940 000 00935 COND SAFTY 0.001µF 250V 20%
C920 9940 000 01086 COND DISC 0.01µF 1KV 20%
C921 9940 000 01086 COND DISC 0.01µF 1KV 20%
C922 9940 000 01086 COND DISC 0.01µF 1KV 20%
C923 9940 000 00935 COND SAFTY 0.001µF 250V 20%
C926 9940 000 01086 COND DISC 0.01µF 1KV 20%
C927 9940 000 01086 COND DISC 0.01µF 1KV 20%
C928 9940 000 01085 COND DISC 0.001µF 1KV 20%
C958 9940 000 01085 COND DISC 0.001µF 1KV 20%
C982 9940 000 00936 COND DISC 470PF 1KV 10%
C985 9940 000 00936 COND DISC 470PF 1KV 10%
C986 9940 000 00936 COND DISC 470PF 1KV 10%
C987 9940 000 00936 COND DISC 470PF 1KV 10%
C988 9940 000 00936 COND DISC 470PF 1KV 10%
C989 9940 000 00936 COND DISC 470PF 1KV 10%
C990 9940 000 00936 COND DISC 470PF 1KV 10%
C991 9940 000 00936 COND DISC 470PF 1KV 10%
C992 9940 000 00936 COND DISC 470PF 1KV 10%
C993 9940 000 00936 COND DISC 470PF 1KV 10%
C994 9940 000 00937 COND DISC 220PF 1KV 10%
C996 9940 000 00937 COND DISC 220PF 1KV 10%
C999 9940 000 00936 COND DISC 470PF 1KV 10%
D902 9940 000 00938 DIODE PR1507 1.5A 1000V
D904 9940 000 00938 DIODE PR1507 1.5A 1000V
D951 9940 000 01571 DIODE FR107 1A 1000V
F901 9940 000 01567 FUSE 4A 250V
IC901 9940 000 00945 IC 8PIN KA5M02659RN
IC902 9940 000 00946 OPTICAL SENSOR 4P
IC953 9940 000 00949 IC 8PIN JRC4558D
IC954 9940 000 00951 IC 16PIN KA7500C
IC955 9940 000 01572 IC 3P TL431
L901 9940 000 00953 AC FILTER 25MH
L954 9940 000 01568 TOROID COIL S1=2TS
Q901 9940 000 01573 MOSFET STP9NK50Z
Q902 9940 000 01573 MOSFET STP9NK50Z
Note: Only these parts mentioned in the list are
Q956 9940 000 01575 FET STP16NF06 16A 60V
normal service parts.
RT901 9940 000 00957 NTC 5Ω 5A
!
!
!
!
!
!
!
!
!
!
!
!
