Philips FWM37 - Page 54

54 FW-M37
37 36
18193127 11 125161739(2X) 24
53(2x)
38
34
75
3892
32
4612(2x)1343(2x)46(6x)47(4x)
2223151426
2142282949(2X)
35
50(10x)
33
41
NO. PART DESCRIPTION QTY
46 HARDEN SCREW STTB 3X6 6
47 HARDEN SCREW TB/WH3X12 4
48 HARDEN SCREW BTTB3X10 51
49 SELF TAPPING SCREWTB/BH3X14 2
50 HARDEN SCREW TT/WH3X6 10
51 HARDEN SCREW TT/BH3X8 5
52 HARDEN SCREW BTTB2.5X10 2
53 SELF TAPPING SCREW TB/BH3X12 2
SCREW LIST
VISTA EXPLODIDA
