Philips GC3331 User Manual

GC3331
2-5
THERMOSTAT DIAL 1
BACKPLATE 2
CORDSET 3
BALL SWIVEL 4
Remove Screw A (1x)
Remove BACKPLATE 2
Remove Screw B (2x)
Remove Cord clamp
INLAY 5
SUB-INLAY PRINTED 6
FILLING DOOR ASSY 7
STEAM SLIDER 8
LAMP ASSY 9
SOS KNOB 11
SPRAY KNOB 12
TANK TOP SEAL 13
Remove Screw A (1x)
Remove BACKPLATE 2
Remove FILLING DOOR ASSY 7
Remove Screw C (1x)
Remove SUB-INLAY 6
Remove INLAY 5
DISASSEMBLY ADVICE
CLAMP BRACKET 14
DOSING CAM 15
STEAM SHAFT ASSY 16
SHAFT BELLOW 17
Remove Screw A (1x)
Remove BACKPLATE 2
Remove FILLING DOOR ASSY 7
Remove Screw C (1x)
Remove SUB-INLAY 6
Remove INLAY 5
Remove SOS KNOB 11
Remove SPRAY KNOB 12
Remove Screw D (2x)
Remove CLAMP BRACKET 14
HOUSING PRINTED 18
PLASTIC RATTLE SPRING 19
PUMP ASSY 20
WATER TANK ASSY 21
ORIFICE 22
THERMOSTAT BUSH 23
VALVE BELLOW ASSY 29
Remove Screw A (1x)
Remove BACKPLATE 2
Remove Screw B (2x)
Remove Cord clamp
Remove FILLING DOOR ASSY 7
Remove Screw C (1x)
Remove SUB-INLAY 6
Remove INLAY 5
Remove Screw E (2x)
Remove THERMOSTAT DIAL 1
Remove HOUSING PRINTED 18
Remove Screw F (2x)
Remove WATER TANK ASSY 21
HEAT SHIELD 24
COVER 25
SOS SEAL 26
DOSING SEAL 27
SOLEPLATE ASSY 28
Remove Screw A (1x)
Remove BACKPLATE 2
Remove Screw B (2x)
Remove Cord clamp
Remove FILLING DOOR ASSY 7
Remove Screw C (1x)
Remove SUB-INLAY 6
Remove INLAY 5
Remove Screw E (2x)
Remove Screw F (2x)
Remove WATER TANK ASSY 21
Remove Screw G (3x)
Remove HEAT SHIELD 24
Remove COVER 25

Philips GC3331 Specifications

Power

power	1100 W
voltage	110 V
frequency	50-60 Hz

Steam

steam boost	95 g/min
continuous steam	35 g/min
water tank capacity	300 ml

Weight and Dimensions

dimensions	328 x 129 x 163 cm
weight	1.64 kg
