Philips GC8210 - Page 5

GC8210
5-9
TRAY RUBBER (MAIN) 30
TRAY 33
STAND TOP 34
FRONT PANEL PRINTED 37
BOILER ASSY ME 38
PRESSOSTAT 39
ELECTROVALVE 40
TRIAC CIRCUIT 43
LIGHT SWITCH 44
PUMP ASSY 45
INLET TUBE 46
DE-AIR TUBE 47
SAFETY CAP ASSY 52
REED SWITCH ASSY 53
CORDSET 55
STAND BOTTOM 56
Remove TRAY RUBBER (MAIN) 30 (3x)
Remove Screws F1, F2, F3
Disassemble TRAY 33
Remove WATER TANK ASSY 58
Remove Screws G1, G2, G3, G4
Disconnect INLET TUBE 46
Disconnect DE-AIR TUBE 47
Remove SAFETY CAP ASSY 52
Disassemble STAND TOP 34
Remove Screws H1, H2
Disassemble FRONT PANEL PRINTED 37
DISASSEMBLY ADVICE - STAND & DETACHABLE WATER TANK
WATER TANK ASSY 70
TANK WASHER 71
TANK COUPLING 73
TANK LEVER 75
PICK UP TUBE 77
FILTER ASSY 78
Remove Screws J1
Disassemble TANK WASHER 71
Remove SCREWS J2, J3
Disassemble TANK COUPLING 73
