Philips GC9610 Service Manual

GC  GC

Disassembly advice Iron & Lock assy
INLAY & LIGHT STRIP 1
MICROSWITCH & REFLECTOR ASSY 2
TRIGGER SPRING 4
TRIGGER 5
HOUSING CAP 6
HOUSING 8
Remove Screw A
Remove INLAY & LIGHT STRIP 
Remove Screw B, B, B & B
Remove MICRO SWITCH & REFLECTOR ASSY 
Remove TRIGGER SPRING 
Remove TRIGGER 
Remove HOUSING CAP 
Remove Screw C
Remove Screw D & D
Remove HOUSING 
GROMMET 7
CORD CLAMP 9
RUBBER BUNG 11 & RYTON RING 12
CHASSIS 10
SOLEPLATE ASSY 13
Remove Screw E & E
Remove GROMMET 
Remove Screw F & F
Remove CORD CLAMP 
Disconnect All wire connection
Remove RUBBER BUNG 
Remove RYTON RING 
Remove Mica sheet
Remove Screw G, G, G & G
Remove CHASSIS 
Remove SOLEPLATE ASSY 
Remove Screw H
Remove Thermistor
FRONT LOCK SLIDER SPRING 16H
FRONT LOCK CATCH SPRING 16G
Remove Screw J  J
Remove Tray
Remove FRONT LOCK SLIDER SPRING H
Remove Lock assy
Remove Screw K, K, K & K
Remove Front lock bracket
Remove FRONT LOCK CATCH SPRING G
UI POWER BOARD 23
BUTTON FRAME 24
POWER BUTTON 25
Remove TRAY 
Remove Screw L, L & L
Remove IU BOARD PCBA 
Remove Screw M & M
Remove BUTTON FRAME 
Remove POWER BUTTON 
