Philips GC9610 Service Manual

GC  GC

Disassembly advice  Stand
WATER TANK ASSY 15
TRAY RUBBER CAP 17
BUNG 51
STAND TOP 19
RETURN TUBE 29
Remove WATER TANK ASSY 
Remove TRAY RUBBER CAP 
Remove BUNG 
Remove Screw A  A
Remove STAND TOP 
Remove RETURN TUBE 
INLET SUPPORT SEAL 30
INLET SUPPORT PLATE 31
INLET COUPLING SUPPORT 32
Remove Screw B & B
Remove INLET SUPPORT SEAL 
Remove INLET COUPLING PLATE 
Disconnect Tube
Remove INLET COUPLING SUPPORT 
POWER BOARD PCBA ASSY 20
PCBA HOLDER 21
HALL SENSOR PCBA ASSY 22
PUMP SUPPORT 28A & 18B
CORRUGATED ELBOW TUBE 27
BRAIDED RUBBER HOSE 33
PUMP ASSY 26
Remove Screw C  C
Remove POWER BOARD PCBA ASSY 
Remove PCBA HOLDER 
Disconnect All wire connection
Remove HALL SENSOR PCBA ASSY 
Remove PUMP SUPPORT A & B
Remove CORRUGATED ELBOW TUBE 
Remove Inox clamp
Remove Hose clip
Remove BRAIDED RUBBER HOSE 
Remove PUMP ASSY 
SAFETY CAP 38B
SAFETY VALVE 38A
E-VALVE 37
RINSE CAP ASSY 42
SPACER TOP 46
SPACER BOTTOM 47
BOILER ASSY 36
Remove SAFETY CAP B
Remove SAFETY VALVE A
Remove EVALVE 
Remove Hose clip
Remove BRAIDED RUBBER HOSE 
Remove Screw D  D
Remove RINSE CAP 
Remove SPACER TOP 
Remove SPACER BOTTOM 
Remove BOILER ASSY 
CLAMPING PLATE 45
CORD SET 43
CORD CLAMP 44
HOSE CORD MTD ASSY 14
BELT LOOP LEFT 49 & RIGHT 48
STAND BOTTOM 50
Remove Screw E & E
Remove CLAMPING PLATE 
Remove CORD SET 
Remove Screw F & F
Remove CORD CLAMP 
Remove HOSE CORD MTD ASSY 
Remove Screw G, G & G
Remove BELT LOOP LEFT 
Remove Screw H, H & H
Remove BELT LOOP RIGHT 
Remove STAND BOTTOM 
