Philips HD9220/20 - Technical Information

HD9220/20 /21 /22 /23 /24
2-10
IMPORTANT:
When you replace the pan (basketholder) or basket,  rst check production week on the bottom of the appliance
to  nd out which part(s) you need to order:
HD9220/2x Pan Basket
1111 4222 459 54131 and 4222 459 54111 Due to compatibility issues, make sure you order both components
1111  1136
4222 459 54131 or 4222 459 49081 Components are compatible no need to be ordered both at once
 1136
4222 459 54131 or 4222 459 54111 Components are compatible no need to be ordered both at once
TECHNICAL INFORMATION
Electrical circuit
When the appliance does not work, check the electrical circuit.
Open de lid panel always on the underside. Always replaces this panel in case of damaged, scratches body or broken click
connection.
L
Thermostat
N
E
Resistor
Orange
Neon lamp
Resistor
Green
Neon lamp
M
HeaterMotor
Therm.
Fuse
220 - 240 V
50 - 60 Hz
RD
BK
BL
WT
YL
GN
= Red
= Black
= Blue
= White
= Yellow
= Green
RD
YL & GN
YL & GN
BL
BK BK
BK
WT
BK
WT
BL
WT
BL
WT
BL
WT WT
