General description (fig. 1)
A Louvre grille (rotating air stream diffuser)
B Timer knob (rotate)
C Louvre rotation on/off knob (push)
D Speed control (rotate) with pilot light
E Automatic safety switch
F Stand (3 positions)
G Hand grip
H Cord storage
I Fixing nut holding the Louvre grill
J Fixing screws holding the air inlet grill
Operation
Getting the fan ready for use
- Set the fan to the required position (fig. 2).
(The stand has three positions.)
- Pull the required length of mains cord out of the
cord storage compartment (fig. 3).
- Insert the mains plug into a wall socket.
- Set the timer knob (B) to the “on” position (fig. 4).
Please note: The appliance cannot switched on,
unless the timer knob has been set to position
“on” or to any required operation time. See also
section “Timer”.
- Select the required air speed by setting switch
(D) (fig. 5).
(0 = stop; 1 = low speed; 2 = medium speed;
3 = maximum speed.)
The pilot light comes on and the fan begins to
work.
Louvre (rotating air flow diffuser) (A)
- For continuously varying the air flow direction
set switch (C) to the “on” position.
The Louvre air diffuser will start to rotate (fig. 6).
- For fixed air-flow direction set switch (C) to the
“on” position and let the air diffuser rotate until
the required air-flow direction is obtained.
Then set switch (C) to “off” position (fig. 7).
Timer (B)
- If you wish the fan to run for a pre-set length of
time (max. 3 hours) and then switch off, set the
timer to the required time by turning knob (B)
clockwise (fig. 8).
Cleaning
• Always remove the mains plug from the wall
socket before cleaning.
• Clean with a soft dry or damp cloth, if required
with a soapy detergent. Do not use abrasives or
solvents.
- For cleaning the front part of the fan, loosen the
fixing nut (I) which holds the Louvre grille
(fig. 9). You can use a coin for this purpose.
(Turn anti-clockwise.)
This enables you to remove the Louvre grille
(fig. 10).
- For cleaning the back part of the fan, loosen the
two fixing screws (J) which hold the air inlet
grille (fig. 11). (Turn anti-clockwise.)
This enables you to remove the air inlet grille
(fig. 12).
English
Important
• Read the instructions in conjunction
with the illustrations before using for
the first time.
• Before you plug the appliance in, check
if the voltage specified on the appliance
corresponds to the mains voltage in
your home.
• Never immerse any part of the appliance
in water or any other liquid.
• Never put objects into the grille when
the fan is connected to the mains.
• Keep a watchful eye on children. Never
allow them to play with the fan.
• It is not advisable to expose people
(esp. babies and older people) to a
continuous cold air stream for a long
time.
• Keep the fan away from lace curtains,
plants etc.
• An automatic safety switch (E) will
switch off the fan if lifted or turned over
during operation.
• If the mains cord of this appliance is
damaged, it must only be replaced by
Philips or their service representative,
as special tools and/or parts are
required.
