HR7735/55
8-8
REPAIR INSTRUCTION
To remove the toothed wheel:
1. Remove the retaining ring with a screwdriver.
To replace the Motor:
1. Remove the 3 screws from the Airtunnel.
After removing the Airtunnel, you can exchange the motor,
the belt or the belt tension.
