Philips HTB3540 Service Manual

DVIDQGZPYÀOHVLQ$6)FRQWDLQHU
Audio codec Video codec Bit rate
Dolby Digital,
MP3, WMA,
DD+
MPEG 4 ASP 38.4 Mbps
H.264/AVC
HiP@4.2
25 Mbps
WMV9 45 Mbps
PSJDQGPSHJÀOHVLQ36FRQWDLQHU
Audio codec Video codec Bit rate
PCM, DTS core,
MPEG, MP3
MPEG 1,
MPEG 2
40
Mbps
ÁYÀOHVLQ)/9FRQWDLQHU
Audio
codec
Video codec Bit rate
MP3,
AAC
H.264/AVC upto
HiP@4.2
25 Mbps
H.263 38.4 Mbps
JSÀOHVLQ*3FRQWDLQHU
Audio
codec
Video codec Bit rate
AAC, HE-
AAC
MPEG 4 ASP 38.4 Mbps
H.264/AVC upto
HiP@4.2
25 Mbps
max
UPUYDQGUPYEÀOHVLQ50FRQWDLQHU
$YDLODEOHRQO\LQ$VLD3DFLÀFDQG&KLQD
Audio codec Video codec Bit rate
AAC, COOK RV30, RV40 40 Mbps
$PSOLÀHU
 Total output power: 1000W RMS (30%
THD)
 Frequency response: 20 Hz-20 kHz /
±3 dB
 Signal-to-noise ratio: > 65 dB (CCIR) /
(A-weighted)
 Input sensitivity:
 AUX: 2 V
 AUDIO IN: 1 V
Video
 Signal system: PAL / NTSC
 HDMI output: 480i/576i, 480p/576p, 720p,
1080i, 1080p, 1080p24
Audio
 S/PDIF Digital audio input:
 Coaxial: IEC 60958-3
 Optical: TOSLINK
 Sampling frequency:
 MP3: 32 kHz, 44.1 kHz, 48 kHz
 WMA: 44.1 kHz, 48 kHz
 Constant bit rate:
 MP3: 32 kbps - 320 kbps
 WMA: 48 kbps - 192 kbps
Radio
 Tuning range:
 Europe/Russia/China: FM 87.5-108
MHz (50 kHz)
 $VLD3DFLÀF/DWLQ$PHULFD)0
MHz (50/100 kHz)
 Signal-to-noise ratio: FM 50 dB
 Frequency response: FM 180 Hz-12.5 kHz
/ ±3 dB
USB
 Compatibility: Hi-Speed USB (2.0)
 Class support: USB Mass Storage Class
(MSC)
 File system: FAT16, FAT32, NTFS
 USB port: 5V
, 500mA (for each port)
Main unit
 Power supply:
 Europe/China: 220-240 V~, 50 Hz
 /DWLQ$PHULFD$VLD3DFLÀF
V/220-240 V~, 50-60 Hz
1-5

Philips HTB3540 Specifications

General

Number of satellite speakers	2
Satellite speakers RMS power	166 W
Satellite speaker frequency range	150 - 20000 Hz
Satellite speaker woofer diameter (imperial)	3 \
Subwoofer type	Passive subwoofer
Bass adjustment	Yes
Subwoofer frequency range	20 - 150 Hz
Subwoofer driver diameter (imperial)	8 \
Supported radio bands	FM
Preset stations quantity	40
AC input voltage	220-240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	160 W
MP3 bit rates	32 - 320 Kbit/s
Audio decoders	DTS-HD Master Audio, Dolby Digital Plus, Dolby TrueHD
RMS rated power	1000 W
Audio output channels	5.1 channels
Audio formats supported	AAC, ADTS, FLAC, MKA, MP3, OGG, Vorbis, WAV, WMA
Total Harmonic Distortion (THD)	30 %
Battery type	AAA
Package type	Carton
Package weight	16.31 kg
Picture enhancement	Rotate, Zoom, HD (720p, 1080i, 1080p/ 24fps)
Image formats supported	GIF, JPG, PNG
Tare weight outer carton	1.62 kg
Cables included	AC, HDMI
USB version	2.0
HDMI version	1.4
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) out	0
Aspect ratio	21:9
Video upscaling	No
Video formats supported	AVCHD, DIVX HD, H.264, ISO, MPEG1, MPEG2, MPEG4, WMV9
Disc types supported	BD, BD-R, BD-RE, CD, CD-DA, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Playback disc formats	SVCD, VCD
Optical disc player type	Blu-Ray player
Consumer Electronics Control (CEC)	EasyLink
Product color	Black
Type of shelf-placement	Laying
Package depth	400 mm
Package width	669 mm
Package height	430 mm

Weight and Dimensions

Main unit weight	2660 g
Subwoofer weight	3660 g
Center speaker weight	650 g
Main unit dimensions (WxDxH)	435 x 286.5 x 56.3 mm
Subwoofer dimensions (WxDxH)	178 x 343 x 303 mm
Front speaker dimensions (WxDxH)	90 x 82 x 185 mm
Center speaker dimensions (WxDxH)	223 x 80 x 102 mm
