Philips HTB3540 Service Manual

Pin Symbol Type Description
AC1
ʳ
NFD7
I/O
Multiple function
(1) NAND Flash Data input/output bit7
(2) GPIO
AD3
ʳ
NFRBN
I/O
Multiple function
(1) NAND Flash ready/busy
(2) GPIO
AE3
ʳ
NFRBN2
I/O
Multiple function
(1) NAND Flash 2
nd
ready/busy
(2) 2nd RS232 RX
(3) External Interrupt 1
(4) 3th RS232 RX
(5) Slave I2C data
(6) PWM control signal output
(7) GPO
AE4
ʳ
NFREN
I/O
Multiple function
(1) NAND Flash read enable
(2) GPO
AD6
ʳ
NFWEN
I/O
Multiple function
(1) NAND Flash write enable
(2) GPO
Dram Channel A
AA25
ʳ
RA0
O
Memory address bit 0
U21
ʳ
RA1
O
Memory address bit 1
AB25
ʳ
RA2
O
Memory address bit 2
AA23
ʳ
RA3
O
Memory address bit 3
W21
ʳ
RA4
O
Memory address bit 4
AA24
ʳ
RA5
O
Memory address bit 5
W22
ʳ
RA6
O
Memory address bit 6
AB24
ʳ
RA7
O
Memory address bit 7
W20
RA8
O
Memory address bit 8
AC24
ʳ
RA9
O
Memory address bit 9
AD23
ʳ
RA10
O
Memory address bit 10
V22
ʳ
RA11
O
Memory address bit 11
AA20
ʳ
RA12
O
Memory address bit 12
AD25
ʳ
RA13
O
Memory address bit 13
Y24
ʳ
RBA0
O
Memory bank address bit 0
9-13

Philips HTB3540 Specifications

General

Number of satellite speakers	2
Satellite speakers RMS power	166 W
Satellite speaker frequency range	150 - 20000 Hz
Satellite speaker woofer diameter (imperial)	3 \
Subwoofer type	Passive subwoofer
Bass adjustment	Yes
Subwoofer frequency range	20 - 150 Hz
Subwoofer driver diameter (imperial)	8 \
Supported radio bands	FM
Preset stations quantity	40
AC input voltage	220-240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	160 W
MP3 bit rates	32 - 320 Kbit/s
Audio decoders	DTS-HD Master Audio, Dolby Digital Plus, Dolby TrueHD
RMS rated power	1000 W
Audio output channels	5.1 channels
Audio formats supported	AAC, ADTS, FLAC, MKA, MP3, OGG, Vorbis, WAV, WMA
Total Harmonic Distortion (THD)	30 %
Battery type	AAA
Package type	Carton
Package weight	16.31 kg
Picture enhancement	Rotate, Zoom, HD (720p, 1080i, 1080p/ 24fps)
Image formats supported	GIF, JPG, PNG
Tare weight outer carton	1.62 kg
Cables included	AC, HDMI
USB version	2.0
HDMI version	1.4
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) out	0
Aspect ratio	21:9
Video upscaling	No
Video formats supported	AVCHD, DIVX HD, H.264, ISO, MPEG1, MPEG2, MPEG4, WMV9
Disc types supported	BD, BD-R, BD-RE, CD, CD-DA, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Playback disc formats	SVCD, VCD
Optical disc player type	Blu-Ray player
Consumer Electronics Control (CEC)	EasyLink
Product color	Black
Type of shelf-placement	Laying
Package depth	400 mm
Package width	669 mm
Package height	430 mm

Weight and Dimensions

Main unit weight	2660 g
Subwoofer weight	3660 g
Center speaker weight	650 g
Main unit dimensions (WxDxH)	435 x 286.5 x 56.3 mm
Subwoofer dimensions (WxDxH)	178 x 343 x 303 mm
Front speaker dimensions (WxDxH)	90 x 82 x 185 mm
Center speaker dimensions (WxDxH)	223 x 80 x 102 mm
