Philips HTB3540 Service Manual

Pin Symbol Type Description
AE13
ʳ
RDQ3_B
I/O
Memory data bit 3
AD21
ʳ
RDQ4_B
I/O
Memory data bit 4
AC21
ʳ
RDQ5_B
I/O
Memory data bit 5
AD20
ʳ
RDQ6_B
I/O
Memory data bit 6
AC20
ʳ
RDQ7_B
I/O
Memory data bit 7
AC15
ʳ
RDQ8_B
I/O
Memory data bit 8
AC16
ʳ
RDQ9_B
I/O
Memory data bit 9
AB15
ʳ
RDQ10_B
I/O
Memory data bit 10
AB14
RDQ11_B
I/O
Memory data bit 11
AC19
ʳ
RDQ12_B
I/O
Memory data bit 12
AE18
ʳ
RDQ13_B
I/O
Memory data bit 13
AE19
ʳ
RDQ14_B
I/O
Memory data bit 14
AD18
ʳ
RDQ15_B
I/O
Memory data bit 15
AB16
ʳ
RDQM0_B
O
Memory data mask bit 0
AA15
ʳ
RDQM1_B
O
Memory data mask bit 1
AD16
ʳ
RDQS0_B
I/O
Memory positive data strobe bit 0
AE16
ʳ
RDQS0__B
I/O
Memory negative data strobe bit 0
AD17
ʳ
RDQS1_B
I/O
Memory positive data strobe bit 1
AC17
ʳ
RDQS1__B
I/O
Memory negative data strobe bit 1
AD10
ʳ
RODT_B
O
Memory on die termination enable
AE11
ʳ
RRAS__B
O
Memory row address strobe
Y18
ʳ
RVREF0_B
I
Memory VREF
AA12
ʳ
RWE__B
O
Memory write enable
AE7
RRESET_B
O
Memory reset
MISC
A19
ʳ
CEC
I/O, 5V
Multiple function
(1) HDMI CEC
(2) GPIO
(3) JTAG ICE data in
9-16

Philips HTB3540 Specifications

General

Number of satellite speakers	2
Satellite speakers RMS power	166 W
Satellite speaker frequency range	150 - 20000 Hz
Satellite speaker woofer diameter (imperial)	3 \
Subwoofer type	Passive subwoofer
Bass adjustment	Yes
Subwoofer frequency range	20 - 150 Hz
Subwoofer driver diameter (imperial)	8 \
Supported radio bands	FM
Preset stations quantity	40
AC input voltage	220-240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	160 W
MP3 bit rates	32 - 320 Kbit/s
Audio decoders	DTS-HD Master Audio, Dolby Digital Plus, Dolby TrueHD
RMS rated power	1000 W
Audio output channels	5.1 channels
Audio formats supported	AAC, ADTS, FLAC, MKA, MP3, OGG, Vorbis, WAV, WMA
Total Harmonic Distortion (THD)	30 %
Battery type	AAA
Package type	Carton
Package weight	16.31 kg
Picture enhancement	Rotate, Zoom, HD (720p, 1080i, 1080p/ 24fps)
Image formats supported	GIF, JPG, PNG
Tare weight outer carton	1.62 kg
Cables included	AC, HDMI
USB version	2.0
HDMI version	1.4
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) out	0
Aspect ratio	21:9
Video upscaling	No
Video formats supported	AVCHD, DIVX HD, H.264, ISO, MPEG1, MPEG2, MPEG4, WMV9
Disc types supported	BD, BD-R, BD-RE, CD, CD-DA, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Playback disc formats	SVCD, VCD
Optical disc player type	Blu-Ray player
Consumer Electronics Control (CEC)	EasyLink
Product color	Black
Type of shelf-placement	Laying
Package depth	400 mm
Package width	669 mm
Package height	430 mm

Weight and Dimensions

Main unit weight	2660 g
Subwoofer weight	3660 g
Center speaker weight	650 g
Main unit dimensions (WxDxH)	435 x 286.5 x 56.3 mm
Subwoofer dimensions (WxDxH)	178 x 343 x 303 mm
Front speaker dimensions (WxDxH)	90 x 82 x 185 mm
Center speaker dimensions (WxDxH)	223 x 80 x 102 mm
