Philips HTB3540 Service Manual

Pin Symbol Type Description
E20
ʳ
UATXD
I/O, 5V
Reserved for debug-only Uart pins
(1) 1
st
RS232 TX
(2) T8032 RS232 TX
A22
ʳ
VCLK
I/O, 5V
Multiple function
(1) VFD clock
(2) GPIO
(3) Slave I2C data
(4) Serial interface data line
A23
ʳ
VDATA
I/O, 5V
Multiple function
(1) VFD data
(2) GPIO
(3) External Interrupt 3
B23
ʳ
VSTB
I/O, 5V
Multiple function
(1) VFD strobe
(2) GPIO
(3) Slave I2C clock
(4) Serial interface control line
AA1
ʳ
SCL
I/O, 5V
Multiple function
(1) Serial interface control line
(2) Slave I2C clock
(3) GPIO
AA2
ʳ
SDA
I/O, 5V
Multiple function
(1) Serial interface data line
(2) Slave I2C data
(3) GPIO
USB
AA3 AVDD33_USB
Power
3.3V Analog power for USB
W4 AVSS33_USB
Ground
Analog ground for USB
W2 USB_DM_P0
Analog
USB port0 differential serial data bus (minus)
W1 USB_DP_P0
Analog
USB port0 differential serial data bus (plus)
Y2 USB_DM_P1
Analog
USB port1 differential serial data bus (minus)
Y1 USB_DP_P1
Analog
USB port1 differential serial data bus (plus)
V2 USB_DM_P2
Analog
USB port2 differential serial data bus (minus)
V1 USB_DP_P2
Analog
USB port2 differential serial data bus (plus)
U3 USB_VRT
Analog
USB reference resistor
E-fuse
W7
ʳ
EFPWRQ
Power 2.5V power for E-fuse programming
Ethernet PHY
G9 AVDD33_LD
Power Line driver 3.3V analog power
9-19

Philips HTB3540 Specifications

General

Number of satellite speakers	2
Satellite speakers RMS power	166 W
Satellite speaker frequency range	150 - 20000 Hz
Satellite speaker woofer diameter (imperial)	3 \
Subwoofer type	Passive subwoofer
Bass adjustment	Yes
Subwoofer frequency range	20 - 150 Hz
Subwoofer driver diameter (imperial)	8 \
Supported radio bands	FM
Preset stations quantity	40
AC input voltage	220-240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	160 W
MP3 bit rates	32 - 320 Kbit/s
Audio decoders	DTS-HD Master Audio, Dolby Digital Plus, Dolby TrueHD
RMS rated power	1000 W
Audio output channels	5.1 channels
Audio formats supported	AAC, ADTS, FLAC, MKA, MP3, OGG, Vorbis, WAV, WMA
Total Harmonic Distortion (THD)	30 %
Battery type	AAA
Package type	Carton
Package weight	16.31 kg
Picture enhancement	Rotate, Zoom, HD (720p, 1080i, 1080p/ 24fps)
Image formats supported	GIF, JPG, PNG
Tare weight outer carton	1.62 kg
Cables included	AC, HDMI
USB version	2.0
HDMI version	1.4
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) out	0
Aspect ratio	21:9
Video upscaling	No
Video formats supported	AVCHD, DIVX HD, H.264, ISO, MPEG1, MPEG2, MPEG4, WMV9
Disc types supported	BD, BD-R, BD-RE, CD, CD-DA, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Playback disc formats	SVCD, VCD
Optical disc player type	Blu-Ray player
Consumer Electronics Control (CEC)	EasyLink
Product color	Black
Type of shelf-placement	Laying
Package depth	400 mm
Package width	669 mm
Package height	430 mm

Weight and Dimensions

Main unit weight	2660 g
Subwoofer weight	3660 g
Center speaker weight	650 g
Main unit dimensions (WxDxH)	435 x 286.5 x 56.3 mm
Subwoofer dimensions (WxDxH)	178 x 343 x 303 mm
Front speaker dimensions (WxDxH)	90 x 82 x 185 mm
Center speaker dimensions (WxDxH)	223 x 80 x 102 mm
