Philips HTB3540 Service Manual

Pin Symbol Type Description
L3
ʳ
FECMOD
3.3V LVTTL
I/O,
5V-tolerance,
Slow slew,
2, 4, 6, 8mA
PDR,
75K pull-
down (0V)
High frequency modulation mode selection signal output, or
LDD serial interface command enable. The pin is spike-free at
power-on stage.
P3
ʳ
FEDMO
Analog
Output
Disk motor control output. DAC output.
T1
ʳ
FEEJECT_
3.3V LVTTL
I/O,
5V-tolerance,
6 mA PDR,
75K pull-up
(3.3V)
Eject/stop key input, active low. The pin is spike-free at power-
on stage.
Alternate function :
General IO.
R1
ʳ
FEFG
3.3V LVTTL
I/O,
5V-tolerance,
6 mA PDR,
75K pull-up
(3.3V)
Motor Hall sensor input. The pin is spike-free at power-on
stage.
N1
ʳ
FEFMO
Analog
Output
Feed motor 1 control. DAC output.
N2
ʳ
FEFMO2
Analog
Output
Feed motor 2 control. DAC output.
N3
ʳ
FEFMO3
Analog I/O
Feed motor 3 control. DAC output.
Alternative Function : Auxiliary servo input
M3
FEFMO4
Analog I/O
Feed motor 4 control. DAC output.
Alternative Function : Auxiliary servo input
H4
ʳ
FOO
Analog
Output
Focus servo output. PDM output of focus servo compensator.
A3
ʳ
FPDOCD
Analog Input
Laser Power Monitor Input for CD APC / Differential negative
input
C4
ʳ
FPDODVD
Analog Input
Laser Power Monitor Input for DVD APC / Differential positive
input
L2
ʳ
FEGAINSW1
Analog
Output
Read gain switch. 1
M2
FEGAINSW2
Analog
Output
Read gain switch 2.
L1
ʳ
FEGAINSW3
Analog
Output
Read gain switch 3.
9-21

Philips HTB3540 Specifications

General

Number of satellite speakers	2
Satellite speakers RMS power	166 W
Satellite speaker frequency range	150 - 20000 Hz
Satellite speaker woofer diameter (imperial)	3 \
Subwoofer type	Passive subwoofer
Bass adjustment	Yes
Subwoofer frequency range	20 - 150 Hz
Subwoofer driver diameter (imperial)	8 \
Supported radio bands	FM
Preset stations quantity	40
AC input voltage	220-240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	160 W
MP3 bit rates	32 - 320 Kbit/s
Audio decoders	DTS-HD Master Audio, Dolby Digital Plus, Dolby TrueHD
RMS rated power	1000 W
Audio output channels	5.1 channels
Audio formats supported	AAC, ADTS, FLAC, MKA, MP3, OGG, Vorbis, WAV, WMA
Total Harmonic Distortion (THD)	30 %
Battery type	AAA
Package type	Carton
Package weight	16.31 kg
Picture enhancement	Rotate, Zoom, HD (720p, 1080i, 1080p/ 24fps)
Image formats supported	GIF, JPG, PNG
Tare weight outer carton	1.62 kg
Cables included	AC, HDMI
USB version	2.0
HDMI version	1.4
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) out	0
Aspect ratio	21:9
Video upscaling	No
Video formats supported	AVCHD, DIVX HD, H.264, ISO, MPEG1, MPEG2, MPEG4, WMV9
Disc types supported	BD, BD-R, BD-RE, CD, CD-DA, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Playback disc formats	SVCD, VCD
Optical disc player type	Blu-Ray player
Consumer Electronics Control (CEC)	EasyLink
Product color	Black
Type of shelf-placement	Laying
Package depth	400 mm
Package width	669 mm
Package height	430 mm

Weight and Dimensions

Main unit weight	2660 g
Subwoofer weight	3660 g
Center speaker weight	650 g
Main unit dimensions (WxDxH)	435 x 286.5 x 56.3 mm
Subwoofer dimensions (WxDxH)	178 x 343 x 303 mm
Front speaker dimensions (WxDxH)	90 x 82 x 185 mm
Center speaker dimensions (WxDxH)	223 x 80 x 102 mm
