Mechanical and Dismantling Instructions
Dismantling Instruction
The following guidelines show how to dismantle the player.
3-1
Detailed information please refer to the model set.
Step 1:Open the top cover.Remove 4 screws on the back panel,dismantle the left and right
baffles,then open the top cover.(Figur 1)
Figue 1
