10EN
e LAN
Connect to the LAN input on a
broadband modem or router.
f SD CARD FOR VOD/BD-LIVE ONLY
(Not available in China)
Slot for SD card. The SD card is used to
rent online videos and access BD-Live.
g VIDEO-VIDEO OUT
Connect to the composite video input on
the TV.
h DOCK for iPod
Connect to a Philips dock for iPod or
iPhone. (Model: Philips DCK306x)
Rear right
a ANTENNA FM 75
Signal input from an antenna, cable or
satellite.
b HDMI IN1 / HDMI IN2
Connect to the HDMI output on a digital
device.
c HDMI OUT (ARC)TO TV
Connect to the HDMI input on the TV.
Subwoofer connectors
a Voltageselector(ForAsiaPaciconly)
Switch the voltage selector to the local
power line voltage.
b AC MAINS~
Connect to the power supply.
c (Power indicator)
When the power is on, the power
indicator turns red.
d (Switch on-off)
Press to switch the power on or off.
