Philips HTS3571 - Part List

PART LIST
Loc. Alt Part No. safety Description
MAIN UNIT
1  996510021087  VOLUMEKNOB
2  996510021567  FUNCTIONBUTTON
3  996510021595  DOORLENS
4  996510021566  MINILENS
5  996510021592  DISPLAYLENS
6  996510021588  FLAPDOOR
7  996510021597  FRONTPANEL
9  996510021602  FUNCTION_BTN_BKT
10  996510021586  SOURCEBUTTONBKT
11  996510021601  OPEN/CLOSSBUTTON
12  996510021561  STANDBYBUTTON
13  996510021064  STANDBYLENS
14  996510021569  BTMCABINET
16  996510021607  DVDDOOR
17  996510021248  DVDLOADER
18  996510021564  FAN12V0.55A
19  996510022916  BACKPANEL
20  996510021619  TOPCABINET
23  996510021568  SOURCEBUTTON
25  996510021186  REMOTECONTROL
27  996510028861  PWRCORD2P1788mm
28  996510023858  RUBBERCUSHION
29  996510021942  RUBBERFOOTD14xH4.2
FM  996510004177  TANTENNAFEMALEPLUG
RCA  996500013058  RCACABLE2P1.2M
V1  996510007429  GPFFCCBLE
V3 # 996510021598  FFCCABLE24P60mm
V3 # 996510025411  FFCCABLE24P60mm
A  996510021573  VFD+JACK+VOL+STDBYPCB
A4  996510029645  POWERPCBASS’Y
A5  996510021594  AMPPCBASSY1200W(TI)
A6  996510029644  MAINPCBASS’Y
A7  996510018486  TUNERPACKKST-MT004FS1
SPEAKER
FLFR  996510027049  RUBBERFOOT
RFS  996510013306  RUBBERFOOT-SUB
SPKC  996510021603  SPEAKERBOX-CENTER
SPKML 996510021618  SPEAKERBOX-FRONTLEFT
SPKMR 996510021623  SPEAKERBOX-FRONTRIGHT
SPKRL  996510021624  SPEAKERBOX-REARLEFT
SPKRR 996510021622  SPEAKERBOX-REARRIGHT
SUB  996510021621  SPEAKERBOX-SUB
SCREW
S1  --  SCREWT2.6xP0.91xL8mm
S2  --  SCREWT2.0x0.63PxL5mm
S3  --  SCREWT3.0x1.06PxL8mm
S4  --  SCREWM3.0x0.5PxL6mm
S6  --  SCREWL10xP2.12xT5.0mm
S7  --  SCREWM3.0x0.5PxL6mm
S8  --  SCREWM3.0x0.5PxL6mm
S9  --  T3.5x1.06PxL8mm
MAIN PCB
CN201  996500015859  CONNECTOR4PINP2.0MM
CN202  996510012494  CONNECTOR5PINRED
CN204  996500017367  CONNECTOR8P
CN205  996510012495  CONNECTOR4P
CN206  996500015900  CONNECTOR3PINP=2.0MM
CN208  996500015897  CONNECTOR3PINRED
CN301  996510012497  FPC/FFCCONN.10P
9-2
MAIN PCB
CN303  996500015861  CONNECTORB4B-XH-A4PIN
CN401  996500015895  CONNECTOR5PINP=2.0MM
CN402  996500015862  CONNECTORB2B-XH-A2PIN
CN802  996500015901  CONNECTOR6PINP=2.0MM
CN803  996500015895  CONNECTOR5PINP=2.0MM
IC201  996510012499  IC28P
IC202  996510021937  IC48PKH29LV320DBTC-70G
IC203 # 994000005209  IC3PAZ809NSTR-E1SOT23
IC203 # 996500041284  IC3PSTM809SWX6F3.0V
IC204  996510004289  IC8PTU24C16CS2SOIC
IC205 # 996510021062  IC3PLD1117ADJSOT223
IC205 # 996510027042  IC3PLD1117AL-33-AA33.3V
IC206 # 996510004115  IC54PAS81F641642C-6P
IC206 # 996510009895  IC54PA641604L-6TTSOPII
IC207  996510012500  IC20PINSN74HC244PWR
IC208  996510021955  IC48PSTM32F101C6ALQFPST
IC209  996510021082  IC256PMT1389FXE/SNLQFP
IC210 # 996500027090  IC3PINAP1117E18LA1.8V
IC210 # 996510027889  IC3PLD1117AL-18-AA3
IC3001 # 996500029611  IC8PCO4558ASO8
IC3001 # 996510020341  IC8PD4558SOPSILICORE
IC301 # 996500029611  IC8PCO4558ASO8
IC301 # 996510020341  IC8PD4558SOPSILICORE
IC303 # 996500029611  IC8PCO4558ASO8
IC303 # 996510020341  IC8PD4558SOPSILICORE
IC304  996510012503  IC16PCD4051BMSOICTI
IC305  996510012503  IC16PCD4051BMSOICTI
IC306  996510021056  IC20PWM8781GEDSSSOP
IC309  996510012500  IC20PINSN74HC244PWR
IC501  996510012505  IC48PCS48540-CQZLQFP
IC801  996510012506  IC28PAM5888SL/FHSOP
JK206A# 996510021571  FIBEROPTICALRECEIVER
JK206A# 996510027975  TOSL.JADLR1113-1
JK206B 996510021591  RCAJACK1PORANGEW/GND
JK302  996510004283  RCAJACK4PAUDIO
JK601  996510012507  HDMIJACK19PPDVBT8-19
JK701  996510012481  RCAJACK1PYELLOWW/GND
JK702  996500012609  RCAJACKR/G/B
L707  994000005468  CHOKE1UH5%
Q204  996510012508  XISTRPNPTIP42C
Q903  996500026946  XISTRPNP2SB772P/QNEC
POWER PCB
BD901 # 996500038405  BRIDGEKBU8088A800V
BD901 # 996500041973  BRIDGEKBU8088A800V
BD901 # 996510011372  BRIDGEKBU8088A800V
C902  996500018042  CONDDISC0.01UF1KV20%
C903  996500018042  CONDDISC0.01UF1KV20%
C904  996500018042  CONDDISC0.01UF1KV20%
C905  996500018042  CONDDISC0.01UF1KV20%
C906  996500027115  CAP.SAFTYY1102PF250V
C907  996510012548  GONDSAFETY0.47uF275V
C908  996510022021  CAP.330uF250V10%105
C909  996510022021  CAP.330uF250V10%105
C910 # 996500027124  CONDMETAL1.5UF250V
C910 # 996510018266  CONDMETAL1.5uF250V
C913  996500020264  CONDDISC470PF1KV10%
C915  996510012473  CONDDISC2200pF1KV10%
C917  994000005343  CONDSAFETY0.22UF275V
C918  996500027115  CAP.SAFTYY1102PF250V
C919  996500027115  CAP.SAFTYY1102PF250V
C942  996500032755  CONDMYLAR0.01UF100V5%
C944  996510004633  CONDMYLAR0.1uF100V5%
C965  994000005344  CAP.SAFETYY1560PF400V
CN901 # 996500015936  CONNECTOR4PINP=3.96MM
CN901 # 996510018268  CONNECTOR4PP=3.96mm1
CN902  996500017458  CONNECTOR3PCL3962WVO
CN903  996510021055  CONNECTORB7B-XH-A7PIN
CN904  996500017358  CONNECTOR7P
Loc. Alt Part No. safety Description
