Philips IP65 - SL STRIP 400 TW LED Luminaire Overview; Major Luminaire Components

Installation & User’s Manual SL STRIP 400 TW LED Luminaires
4 SL STRIP 400 TW LED LUMINAIRE OVERVIEW
Sh wline
SL STRIP 400 TW LED LUMINAIRE OVERVIEW
1. SL STRIP 400 TW LED Luminaire Components
Major Luminaire Components
Figure 1: SL STRIP 400 TW LED Luminaire Components
Note: *Mounts can be removed and reversed. See "Mounting Luminaire" on page 9 for more information
Side of Unit
Bottom of Unit
DMX512 /
AC Input
LCD Display / Menu System
Luminaire Mount*
Safety Cable Anchor Point
RDM Input
Top of Unit
DMX512 /
AC Output
RDM Output
Luminaire Mount*
High-Intensity Warm White & Cool White LED Array (x36)
