Philips LTC0450/51 - Technical Specifications

Technical specifications
Low voltage Mains voltage
Medium resolution High resolution Medium resolution High resolution
Type LTC LTC LTC LTC LTC LTC LTC LTC
0430/11 0430/21 0450/11 0450/21 0430/51 0430/61 0450/51 0450/61
TV standard PAL NTSC PAL NTSC PAL NTSC PAL NTSC
Imaging device 1/3” IT CCD
Active pixels 512x582 512x492 752x582 768x492 512x582 512x492 752x582 768x492
(HxV)
Lens mount CS-mount (C-mount using optional adapter ring)
Hor. resolution 340 490 340 490
(TVL)
Min. illumination < 1 lux
S/N > 48dB
Back light Selectable on/off
compensation
Iris control Electronic/Active video iris/DC iris with level adjustment
CVBS output 1 V
pp
(75Ω)
Y/C output No Y: 1 Vpp; C: 0.3 Vpp No Y: 1 Vpp; C: 0.3 Vpp
(75Ω)
White balance Automatic 2500-8000 K
Power supply 12-28 V~(AC); 12-36V
––7
(DC) + 10% - 10% 100-240 V~(AC) + 10% - 15%
polarity independent, with mechanical ground lead without ground
Power < 4.0W
consumption
Synchronization Internal or line lock when AC-powered (V-phase adjustable)
Dimensions 48 x 49 x 119 mm
(WxHxD)
Controls DC iris level (low-high),V-phase adjustment for line lock
Operating -20 to 50°C
temperature
Weight 451 g (excl. lens) 577 g (excl. lens)
Tripod mount Top and bottom, 1/4” -20 UNC
Switches Electronic iris on/off - DC/video, Back light compensation on/off
All data subject to change without notice.
