Philips LTC0600 - Linelock Phase; H Phase; Ext V Phase; 10 Specifications

English
1716
10
Specifications
AGC: 18 dB
Selectable
2
): 24 dB
Automatic shutter: up to 1/100,000 sec.
Selectable
2
): ON, OFF, Flickerless
Manual shutter: 1/60 up to 1/10,000
Selectable
2
):
Auto Black: ON, OFF
Selectable
2
):
Black level: 15 fixed levels
Contouring: H and V symmetrical,
Selectable
2
): 15 fixed levels,Automatic and OFF
Compression: White Compression
Selectable
2
): 15 fixed levels and OFF
Gamma: Contrast Enhancement
Selectable
2
): 15 fixed level, 0.25 up to 1
White Balance: Auto sensing (TTL)
Auto AWB: 2700 K to 10,000 K
Auto store: 2700 K to 10,000 K
Video Output
Video output 1: BNC isolated from mechanical earth, 75 Ω,AC coupled,
nominal 1 V[
p-p
] Pal or NTSC composite,
Video output 2: 4 pin S-VHS connector 75 Ω,AC coupled
S-VHS. Level: Y 1 V[
p-p
], C, 300 m V[
p-p
]. or
Selectable
2
): Balanced output. 2 V[
p-p
] into 150 Ω.Unbalance -20 dB at 5 MHz
Synchronization: Internal crystal reference, Line-locked, H/V-lock, ext V-lock
Sync. Input BNC isolated from mechanical earth
Input impedance: Selectable
2
): 75 Ω or >10 kΩ AC coupled
External H/V lock: Nominal CVBS 1 V[
p-p
] (min. 150 mV, max. 600 mV)
External V-lock: Positive V-pulse, 8%-50% duty cycle, Standard 5 V, Cmos level
Capture time: ≤2 s.
Serial Input/Output: Sub D, 9-pole connector, RS 232 Selectable
2
): 1200, 2400,
4800 baud. Connector pinnings:TX=2, Rx=3, Ground=5
User input: Switch to Mode 3, Mode select input=1, Ground=5. Pull-up
10 kΩ to +5V
Selectable
2
): Active low or active high or disable.
2
) Selection by PC software LTC0650/00
9.2.7 Linelock Phase
This function is active when the camera operates in linelock mode.
9.2.8 H Phase
This function is active when the camera operates with external synchronisation (H+V).
Use the H-phase setting to adjust Horizontal timing differences when cameras are H-V
synchronised. Input standard CVBS synchronisation signals.
9.2.9 ext V Phase
This function is active when the camera operates with external synchronisation.
(External V)
Use the extV phase setting to adjust V phase differences when cameras are used in a
system. Input; Positive V-pulse, 8-50% duty cycle, 5 V CMOS level.
LTC 0600/10 models, PAL
Pick-up Device: 752 (H) x 582 (V) active pixels, Interline Transfer CCD.
Scanning Area: 7.95 (H) x 6.45 (V) mm. Equivalent to 1/2” diagonal scanning area.
Scanning PAL: 625 lines / 50 fields / 25 frames, interlaced
Horizontal: 15.625 kHz
Vertical: 50 Hz
LTC 0600/20 models, NTSC
Pick-up Device: 768 (H) x 494 (V) active pixels, Interline Transfer CCD.
Scanning Area: 7.95 (H) x 6.45 (V) mm. Equivalent to 1/2” diagonal scanning area.
Scanning PAL: 525 lines / 60 fields / 30 frames, interlaced
Horizontal: 15.734 kHz
Vertical: 60 Hz
Horizontal Resolution: 480 TVL
MTF: ≥ 45 % at 4 MHz
Sensitivity: Usable Picture Full Video
Scene illumination:
1
) fc 0.03 0.17
lx 0.3 1.7
Imager illumination: fc 0.003 0.02
lx 0.03 0.2
1
) for f/1.2 lens, 89% scene reflectance and 18 dB AGC
Signal-to-Noise: 50 dB at 1.7 lux (0.17 fc) sensor illumination
(Unified weighting filter in accordance with CCIR Rec. 567)
