Philips LX2600D - Front Board Electrical Parts List

6-7
ELECTRICAL PARTS LIST - FRONT BOARDS
MISCELLANEOUS
1101 4822 265 11515 CONN. BM V 8P F
1103 4822 276 13775 Tach Switch
1104 4822 276 13775 Tach Switch
1105 4822 276 13775 Tach Switch
1106 4822 276 13775 Tach Switch
1107 4822 276 13775 Tach Switch
1108 4822 276 13775 Tach Switch
1111 2422 129 16975 Rotary Encoder 12P
1201 4822 267 10733 CON BM V 4P F
1202 4822 276 13775 Tach Switch
RESISTORS
3100 4822 052 10478 4R70 5% 0,33W
DIODES
6105 4822 130 30621 1N4148
6106 4822 130 30621 1N4148
6108 4822 130 34173 BZX79-C5V6
6109 4822 130 34173 BZX79-C5V6
6110 4822 130 34173 BZX79-C5V6
6112 4822 130 34167 BZX79-B6V2
6201 9322 179 76676 LED VS LTL-816EELC
6202 4822 130 34173 BZX79-C5V6
TRANSISTORS & INTEGRATED CIRCUITS
7100 9322 186 03671 UPD16312GB-3B4
7101 9322 185 95667 IR RECEIVER TSOP4836
7102 4822 130 42804 BC817-25
7103 4822 130 60373 BC856B
7104 5322 130 60159 BC846B
7201 5322 130 60159 BC846B
Note: Only the parts mentioned in this list are normal service
spare parts.
