Philips LX2600D - Amplifier Board Electrical Parts List

8-7
ELECTRICAL PARTS LIST - AMPLIFIER BOARD
MISCELLANEOUS
0010 3104 211 29861 SPRING 6 CHANNEL
1302 4822 267 10729 CON BM V 10P F
1600 2422 540 98514 RES CER 602KHZ7
CSB600F1 B
1601 2422 540 98568 RES CER 700KHZ
CSBLA* B
CAPACITORS
2104 2222 601 55649 100V 100nF 10%
2106 2020 021 91431 100V 22uF 20%
2106 2020 021 91431 100V 22uF 20%
2107 2222 601 55649 100V 100nF 10%
2114 2238 600 15619 100V 560pF 10%
2115 2238 600 15619 100V 560pF 10%
2116 4822 121 51252 50V 470nF 10%
2117 2222 601 55649 100nF 10% 100V
2122 2238 600 15619 100V 560pF 10%
2124 2222 601 55649 100V 100nF 10%
2125 4822 121 51252 50V 479nF 10%
2126 2238 600 15619 100V 560pF 10%
COIL & FILTERS
5102 2422 536 00733 Ind Fixed 22uF 20%
5103 2422 536 00733 Ind Fixed 22uF 20%
5400 4822 157 11411 BEAD 100MHZ 80R
5401 4822 157 11411 BEAD 100MHZ 80R
DIODES
6600 3198 020 55680 BZX384-C5V6
6713 4822 130 11397 BAS316
6714 4822 130 11397 BAS316
6715 4822 130 11397 BAS316
TRANSISTORS & INTEGRATED CIRCUITS
7100 9352 753 45518 TDA8922BTH/N2
7600 5322 209 11517 74HCU04D
7602 5322 130 60159 BC846B
7607 5322 209 14477 HEF4013BT
7608 4822 130 60373 BC857B
7710 5322 130 60159 BC847B
7716 4822 130 60373 BC857B
Note: Only the parts mentioned in this list are normal service
spare parts.
