11-1
MAIN ENCASING & ACCESSORIES PARTS LIST
0101 3139 257 51731 CABINET FRONT ASSY (97)
0110 3139 257 51811 COVER TRAY DVD (97)
0113 3139 254 01461 LENS ORN COVER TRAY
0121 3139 254 01411 KNOB VOLUME
0123 3143 027 60431 KNOB VOLUME ASSY
0254 4822 532 60948 BUSH
0101 3139 257 51771 CABINET FRONT ASSY (93)
0110 3139 257 51801 COVER TRAY DVD (93)
FRONT CABINET ASSEMBLY PARTS LIST
0001 3139 257 51711 CABINET FRONT (97)
0003 3139 247 51831 BADGE PHILIPS ASSY
0009 3139 257 51831 BUTTON PWR/STDBY
0011 3139 114 79541 LIGHTGUIDE STANDBY
0013 3139 257 51821 BUTTON SET CONTROL
0019 3139 257 51741 WINDOW DISPLAY
0021 3139 254 01441 WINDOW DISPLAY RIGHT
0001 3139 257 51751 CABINET FRONT (93)
BOTTOM PLATE ASSEMBLY PARTS LIST
0003 3139 243 10080 CUSHION FOOT
0007 2422 015 19894 SADDLE WIRE NY6/6 NT
9.9MM B
0009 8204 055 76161 SPACER LOCKING
KGLS-4S B
0015 2422 015 16901 SADDLE MINI CLAMP
TYPE B 11.8
FINAL EQUIPMENT
ASSEMBLY PARTS LIST
0351 2422 076 00546 CABLE FM AERIAL
0352 2422 549 45813 ANTENNA AM LOOP
0352 2422 549 45386 ANTENNA AM LOOP
0353 3139 238 04751 REMOTE CONTROL
0356 2422 070 98231 MAIN CORD (97)
0356 4822 321 11462 MAINS CORD 20/21"
(JST PLUG)
0364 3103 308 92610 CABLE AUDIO
0365 4822 263 21206 P50 ADAPTOR
0356 2422 070 98232 MAIN CORD (93)
ELECTRICAL ASSEMBLY PARTS LIST
1210 3141 018 05122 DVD LOADER A97SL-F
(CABLE)
1210 3141 018 05182 DVD LOADER A97SL-S
(CABLE)
1211 3139 118 58401 PCBAS SPK CONNECTOR
1212 3139 118 58431 PCBAS MONO AV (97)
1213 3139 118 57202 PCBAS FRONT
1215 3122 429 00401 PSU DVD-RECEIVER
1216 2422 542 90138 TUNNER A+F ENG06703Q
USA B
1212 3139 118 58481 PCBAS MONO AV (93)
SET WIRING ASSEMBLY PARTS LIST
8521 3139 110 34580 Flex Cable 4P 28cm AD
8531 3139 111 03671 Flex Cable 10P 140cm AD
8540 3139 110 35390 Flex Cable 8P 480cm BD
8580 3139 110 35911 Flex Cable 11P 100cm BD
Note: Only the parts mentioned in this list are normal service
spare parts.
