AMPLIFIER SECTION
Output power
- Stereo mode (DIN) 50 W + 50 W RMS
1
- Surround mode (1 kHz) 50 W RMS/channel
Frequency Response 100 Hz – 20 kHz / –3 dB
Signal-to-Noise Ratio > 65 dB (CCIR)
Input Sensitivity
- AUX In 900 mV
- TV In 450 mV
TUNER SECTION
Tuning Range FM 87.5 – 108 MHz (50 kHz)
MW 530 – 1700 kHz
(10 kHz steps)
26 dB Quieting Sensitivity FM 20 dBf
MW 4 mV/m
Image Rejection Radio FM 25 dB
MW 28 dB
IF Rejection Ratio FM 60 dB
MW 24 dB
Signal-to-Noise Ratio FM 60 dB
MW 40 dB
MW Suppression Ratio FM 30 dB
Harmonic Distortion FM Mono 3%
FM Stereo 3%
MW 5%
Frequency Response FM 180 Hz – 10 kHz / ±6 dB
Stereo Separation FM 26 dB (1 kHz)
Stereo Threshold FM 23.5 dB
DISC SECTION
Laser Type Semiconductor
Disc Diametre 12cm / 8cm
Video Decoding MPEG-2 / MPEG-1
Video DAC 12 Bits
Signal System PAL / NTSC
Video Format 4:3 / 16:9
Video S/N 56 dB (minimum)
Composite Video Output 1.0 Vp-p, 75 W
S-Video Output Y - 1.0 Vp-p, 75 W
C - 0.286 Vp-p, 75 W
Audio DAC 24 Bits / 96 kHz
Frequency Response 4 Hz – 20 kHz (44.1 kHz)
4 Hz – 22 kHz (48 kHz)
MAIN UNIT
Power Supply Rating 230 – 240 V; 50 Hz
110 – 127 / 220 – 240 V;
50/60 Hz Switchable
Power Consumption 80 W
Dimensions (w x h x d) 360 mm x 54 mm x 316 mm
Weight 2.9 kg
SPEAKERS
Front speakers / Rear (surround) speaker
System 2 speakers, Bass Reflex
system
Impedance 4 Ω
Speaker drivers 1 x 3” FR, 1 3/4” piezo
Frequency response 120 Hz – 20 kHz
Dimensions (w x h x d) 89 mm x 162 mm x 70 mm
Weight 0.44 kg/each
CENTER SPEAKER
System 3 speakers, Bass Reflex
system
Impedance 4 Ω
Speaker drivers 2 x 3” FR, 1 3/4” piezo
Frequency response 120 Hz – 20 kHz
Dimensions (w x h x d) 234 mm x 96 mm x 70 mm
Weight 0.94 kg
SUBWOOFER
System Bass Reflex system
Impedance 4 Ω
Speaker drivers 6 1/2” woofer
Frequency response 30 Hz – 120 Hz
Dimensions (w x h x d) 220 mm x 230 mm x 360 mm
Weight 4.5 kg
Specifications subject to change without prior notice
