Philips MC-200 - Tape Deck Wiring and Electronics; Tape Mechanism Wiring and Soldering

9 - 49 - 4
1
CRO
Red
Grey
White
Blue
Yellow
REC
RVS
REC
FWD
Tape Deck
Motor
To ETF Board
Connector 1710 (5P)
To ETF Board
Connector 1760 (8P)
TAPE DECK WIRING
PCS 107
TAPE MECHANISM ELECTRONICS
1. Vcc 12V
Pin No.
08FESTVKNA
Mode Switch
CrO2 Switch
Rec Switch (FWD)
Rec Switch (RVS)
Solenoid
Motor
470R
Photo Interrupter
2. Photo Out
3. Gnd
4. Mode Switch
5. Solenoid
6. CrO2 Switch
7. Rec Switch (FWD)
8. Rec Switch (RVS)
Rec/Pb Head
Erase Head
Head
Head wire connector pcb
(05FESTVKNA)
1. +L ch
Pin No.
2. Gnd
3. +R ch
4. E Head
5. E Head
(White)
(Grey)
(Red)
(Blue)
(Yellow)
Mechanism Head Wires Soldering
