Philips MC-200 - Combi Board Electrical Partslist; Miscellaneous and Capacitors

14 - 14
ELECTRICAL PARTSLIST - COMBI BOARD
MISCELLANEOUS CAPACITORS
1330 2422 026 05099 Headphone socket 2505 4822 122 31765 100pF 2% NP0 63V
1331 4822 267 31176 Speaker Socket 2506 4822 122 31765 100pF 2% NP0 63V
1550 4822 265 20553 Aux. In Socket 2507 4822 122 31765 100pF 2% NP0 63V
1551 4822 267 10953 FFC Socket 7P 2508 4822 122 31765 100pF 2% NP0 63V
1554 4822 267 10731 Connector 6P 2509 4822 122 33761 22pF 5% NP0 50V
1555 4822 265 11515 FFC Socket 8P 2510 4822 122 33761 22pF 5% NP0 50V
1556 2422 025 14526 FFC Socket 16P 2511 4822 126 13879 220nF +80-20% 16V
2512 4822 126 13879 220nF +80-20% 16V
2513 4822 122 33777 47pF 5% NP0 63V
CAPACITORS 2514 4822 122 33777 47pF 5% NP0 63V
2251 5322 121 42386 100nF 5% 63V 2515 5322 126 11583 10nF 10% X7R 50V
2252 5322 121 42386 100nF 5% 63V 2516 5322 126 11583 10nF 10% X7R 50V
2253 5322 121 42386 100nF 5% 63V 2517 4822 126 14247 1,5nF 20% 50V
2254 5322 121 42386 100nF 5% 63V 2518 4822 126 14247 1,5nF 20% 50V
2256 4822 124 81151 22µF 20% 50V 2519 4822 126 13883 220pF 5% 50V
2257 4822 124 40248 10µF 20% 63V 2520 4822 126 13883 220pF 5% 50V
2258 4822 124 40769 4,7µF 20% 100V 2521 4822 126 14247 1,5nF 20% 50V
2259 4822 124 40769 4,7µF 20% 100V 2522 4822 126 14247 1,5nF 20% 50V
2260 3198 017 34730 47nF 20% X7R 16V 2523 3198 016 36810 680pF 20% NP0 25V
2262 3198 016 31020 1nF 20% NP0 25V 2524 3198 016 36810 680pF 20% NP0 25V
2264 4822 124 40769 4,7µF 20% 100V 2525 4822 122 33777 47pF 5% NP0 63V
2265 4822 124 40207 100µF 20% 25V 2526 4822 122 33777 47pF 5% NP0 63V
2266 4822 126 14305 100nF 10% X7R 16V 2527 5322 126 11583 10nF 10% X7R 50V
2267 4822 124 40784 3300µF 20% 16V 2528 5322 126 11583 10nF 10% X7R 50V
2268 4822 124 12012 4700µF 20% 25V 2529 4822 126 14305 100nF 10% X7R 16V
2330 4822 124 40769 4,7µF 20% 100V 2530 4822 126 14305 100nF 10% X7R 16V
2331 2238 786 19852 150pF +80-20% 16V 2531 4822 126 14305 100nF 10% X7R 16V
2332 2238 786 19852 150pF +80-20% 16V 2532 4822 126 14305 100nF 10% X7R 16V
2337 4822 121 42408 220nF 5% 63V 2533 3198 017 34730 47nF 20% X7R 16V
2338 4822 121 42408 220nF 5% 63V 2534 3198 017 34730 47nF 20% X7R 16V
2339 4822 121 42408 220nF 5% 63V 2535 4822 126 14305 100nF 10% X7R 16V
2340 4822 121 42408 220nF 5% 63V 2550 4822 126 11585 22nF +80-20% 25V
2341 4822 124 40433 47µF 20% 25V 2551 4822 126 14238 2,2nF 20% 50V
2342 4822 124 40433 47µF 20% 25V 2552 4822 126 14238 2,2nF 20% 50V
2343 4822 122 33197 1nF 10% 50V 2553 4822 126 14494 22nF 10% X7R 25V
2344 4822 122 33197 1nF 10% 50V 2554 4822 124 40196 220µF 20% 16V
2345 4822 126 14494 22nF 10% X7R 25V 2555 4822 124 22652 2,2µF 20% 50V
2346 4822 126 14494 22nF 10% X7R 25V 2557 3198 017 44740 470nF +80-20% 10V
2347 4822 124 40433 47µF 20% 25V 2558 4822 126 13883 220pF 5% 50V
2348 4822 124 40433 47µF 20% 25V 2559 4822 126 13883 220pF 5% 50V
2349 4822 124 40207 100µF 20% 25V 2560 4822 126 13883 220pF 5% 50V
2350 4822 124 40207 100µF 20% 25V 2561 4822 124 81151 22µF 20% 50V
2351 4822 124 40769 4,7µF 20% 100V 2563 4822 124 41407 0,47µF 20% 63V
2352 4822 124 40433 47µF 20% 25V 2564 4822 124 41407 0,47µF 20% 63V
2353 5322 126 11583 10nF 10% X7R 50V 2565 4822 122 31765 100pF 2% NP0 63V
2354 5322 126 11583 10nF 10% X7R 50V 2566 4822 122 31765 100pF 2% NP0 63V
2500 4822 124 41584 100µF 20% 10V 2567 4822 124 22652 2,2µF 20% 50V
2501 4822 124 40196 220µF 20% 16V 2568 4822 124 22652 2,2µF 20% 50V
2502 4822 124 40248 10µF 20% 63V 2569 4822 124 21913 1µF 20% 63V
2503 4822 126 14494 22nF 10% X7R 25V 2570 4822 124 21913 1µF 20% 63V
