Philips MC-200 - LED Board Electrical Partslist; Resistors and Diodes; Power Board and Miscellaneous Partslist; Power Board Components and Miscellaneous Items

14 - 18
ELECTRICAL PARTSLIST - LED BOARD
RESISTORS
3901 4822 051 20121 120R 5% 0,1W
3902 4822 051 20121 120R 5% 0,1W
3903 4822 051 20121 120R 5% 0,1W
3904 4822 051 20121 120R 5% 0,1W
DIODES
6901 9322 033 20682 LED TLHG4405
6902 9322 033 20682 LED TLHG4405
6903 9322 033 20682 LED TLHG4405
6904 9322 033 20682 LED TLHG4405
6905 9322 033 20682 LED TLHG4405
6906 9322 033 20682 LED TLHG4405
6907 9322 033 20682 LED TLHG4405
6908 9322 033 20682 LED TLHG4405
6909 9322 033 20682 LED TLHG4405
6910 9322 033 20682 LED TLHG4405
6911 9322 033 20682 LED TLHG4405
6912 9322 033 20682 LED TLHG4405
ELECTRICAL PARTSLIST - POWER BOARD AND MISCELLANEOUS
1025 4822 276 13963 CD DOOR SWITCH
1600 ! 4822 272 10269 Voltage selector (/21 only)
1601 ! 4822 071 53152 Fuse 3,15A
1602 ! 2422 086 10783 Fuse 2A 250V
5600 ! 4822 157 11832 Mains filter 400µH 3A
5601 ! 3140 118 32430 Mains Transformer 230V
5601 ! 3140 118 32440 Mains Transformer 120/230V
8000 3140 110 21250 FFC Foil 16P 220mm AD
8001 3140 110 21220 FFC Foil 6P 220mm AD
8005 3140 110 21210 FFC Foil 6P 220mm AD
8007 3140 110 21240 FFC Foil 8P 180mm AD
8008 ! 4822 321 10781 Mains Cord Set (/21 /22)
8008 ! 4822 321 10971 Mains Cord Set SAA (/30)
8009 3140 110 21850 FFC Foil 7P 180mm AD
8010 3140 110 21840 FFC Foil 7P 120mm AD
8800 4822 320 12178 FFC Foil 15P 65mm
