Philips MC-45 - Electrical Parts List - Etf8 Board

9-9
RESISTORS
3771 4822 117 11817 1k2 1% 1/16W
3772 4822 051 30153 15k 5% 0,062W AR
3772 4822 051 30123 12k 5% 0,062W Non-AR
3774 4822 051 30183 18k 5% 0,062W
3775 4822 117 13608 4,7R 5% 0,063W
3776 4822 051 30682 6k8 5% 0,062W
3777 4822 051 30151 150R 5% 0,062W
3778 4822 052 10688 6R8 5% 0,33W
3779 4822 051 30334 330k 5% 0,062W
3780 4822 051 30105 1M 5% 0,062W
3781 4822 051 30475 4M7 5% 0,062W
3786 4822 051 30223 22k 5% 0,062W
3789 4822 117 12925 47k 1% 0,063W
3790 4822 051 30223 22k 5% 0,062W
3791 4822 051 30273 27k 5% 0,062W
3796 4822 051 30475 4M7 5% 0,062W
3797 4822 051 30563 56k 5% 0,062W
3800 4822 051 30223 22k 5% 0,062W
4701 4822 051 30008 0R Jumper 0603
4702 4822 051 30008 0R Jumper 0603
4705 4822 051 30008 0R Jumper 0603
4707 4822 051 30008 0R Jumper 0603
4708 4822 051 30008 0R Jumper 0603
4709 4822 051 30008 0R Jumper 0603
4710 4822 051 30008 0R Jumper 0603
4711 4822 051 30008 0R Jumper 0603
4712 4822 051 30008 0R Jumper 0603
4718 4822 051 30008 0R Jumper 0603
4719 4822 051 30008 0R Jumper 0603
4720 4822 051 30008 0R Jumper 0603
4721 4822 051 30008 0R Jumper 0603
4723 4822 051 30008 0R Jumper 0603
4725 4822 051 30008 0R Jumper 0603
4726 4822 051 30008 0R Jumper 0603
4727 4822 051 30008 0R Jumper 0603
4729 4822 051 30008 0R Jumper 0603
4730 4822 051 30008 0R Jumper 0603
4731 4822 051 30008 0R Jumper 0603
4732 4822 051 30008 0R Jumper 0603
4733 4822 051 30008 0R Jumper 0603
4734 4822 051 30008 0R Jumper 0603
4735 4822 051 30008 0R Jumper 0603
4736 4822 051 30008 0R Jumper 0603 Non-AR
4737 4822 051 30008 0R Jumper 0603 Non-AR
4738 4822 051 30008 0R Jumper 0603
4739 4822 051 30008 0R Jumper 0603
4741 4822 051 30008 0R Jumper 0603
4746 4822 051 30008 0R Jumper 0603
4747 4822 051 30008 0R Jumper 0603
COILS & FILTERS
5701 4822 157 62552 Coil 2,2uH 5%
5703 4822 156 20946 Osc Coil 100kHz
DIODES
6612 4822 130 31878 1N4003G
6770 4822 130 30621 1N4148
6771 4822 130 30621 1N4148
6772 4822 130 30621 1N4148
6773 4822 130 30621 1N4148
6774 4822 130 30621 1N4148
6776 4822 130 30621 1N4148
6777 3198 010 58280 BZX79-B8V2
6778 4822 130 30621 1N4148
TRANSISTORS & INTEGRATED CIRCUIT
7610 5322 209 11306 HEF4094BT
7612 4822 130 11201 PMBT2907
7614 4822 130 11201 PMBT2907
7618 4822 130 60511 BC847B
7620 4822 130 60511 BC847B
7624 4822 130 60511 BC847B
7720 9322 167 09668 AN17150ATA
7780 4822 130 60511 BC847B
7781 4822 130 42804 BC817-25
7782 4822 130 44568 BC557B
7783 4822 130 60511 BC847B
7784 4822 130 60373 BC857B
7786 4822 130 63494 J111
7788 4822 130 60511 BC847B
7789 4822 130 60511 BC847B
7790 4822 130 60511 BC847B
Note: Only the parts mentioned in this list are normal service
spare parts.
ELECTRICAL PARTS LIST - ETF8 BOARD
