Philips MC-V65 - Electrical Partslist

13 - 2
ELECTRICAL PARTS LIST
- MISCELLANEOUS - - CAPACITORS -
1101 9965 000 11393 FM ANTENNA TERMINAL 2P 2106 9965 000 11368 CER TRIMMER 3P-11P 100V
CON201 9965 000 14698 CONNECTOR BASE 6P 2155 9965 000 11368 CER TRIMMER 3P-11P 100V
CON202 9965 000 14698 CONNECTOR BASE 6P
CON203 9965 000 14699 CONN 12P TUC-P12X-31
CON204 9965 000 14700 FFC BASE 24PIN H
- RESISTORS -
CON205 9965 000 14510 CON FFC BASE 1.
0 24P
CON401 9965 000 14507 FFC CONNECTOR
16P
3142 9965 000 11363 TRIM-POT CAR LIN 100K H
CON402 9965 000 14701 CONN ASSY 6P 2.0 120 PH R615 9965 000 14719 RES FUSE 2.2R 1/4W
CON403 9965 000 14512 CONNECTOR BASE 2P V R616 9965 000 14719 RES FUSE 2.2R 1/4W
CON501 9965 000 14699 CONN 12P TUC-P12X-31 R773 9965 000 14537 1/2W 1R
CON601 9965 000 14702 CON ASSY 5P 2.5 160MM
CON702 9965 000 14703 CON ASSY 5P 2.5 200MM
CON703 9965 000 14510 CON FFC BASE 1.0 24P
- COILS & FILTERS -
CON801 9965 000 14700 FFC BASE 24PIN H
CON909 9965 000 14704 CONNECTOR 2P 2.0 5102 9965 000 11354 MW RF COIL
5109 9965 000 11355 CER FILTER SFE 10,7MS3AZ
F701 4822 070 13152 FUSE 217 3.15A 5110 9965 000 11355 CER FILTER SFE 10,7MS3AZ
F702 4822 070 32002 FUSE 218 2A 5111 2422 549 44023 IND VAR 7MM 7PY 450KHZ
HP601 9965 000 14524 HEADPHONE JACK 5112 4822 157 70302 F7MCS-12216N
HP901 9965 000 14524 HEADPHONE JACK
J301 9965 000 14705 JACK PIN 1P YEL W /O SW 5114 4822 157 70302 F7MCS-12216N
5119 4822 157 11443 2µ4 1 0M7
J501 9965 000 14706 RCA PIN JACK 2P V 5121 9965 000 14720 X'TAL 75KHZ
LCD801 9965 000 14500 LCD 5123 9965 000 11360 IND VAR 7MM 7PY 796 KHZ
P09 9965 000 14707 CABLE SMF 1P/180/1P 5130 4822 157 11843 MD7B-01F
P12 9965 000 14708 CABLE SRA 1P/200/1P
SP301 9965 000 14709 TERMINAL PIN 5131 4822 157 11843 MD7B-01F
L201 9965 000 11376 IND VAR 7MM 7PA 100KH Z B
SP601 9965 000 14525 TERMINAL SP 4P L301 9965 000 14721 FILTER EMI BL01 RN1
SW
201
9965
000 11378
SWIT
CH SLIDE 6P2T
L302 9965
000 14721
FILTER EMI BL01 RN1
SW701 9965 000 11348 VOLTAGE SELEC TOR 2P 5A L303 9965 000 14721 FILTER EMI BL01 RN1
SW801 4822 276 13775 SWITCH
SW802 4822 276 13775 SWITCH L304 9965 000 14721 FILTER EMI BL01 RN1
L305 9965 000 14722 FIXED A 02 22µ TP 26MM
SW803 4822 276 13775 SWITCH L306 9965 000 14723 COIL 2.2µH K FLR50
SW804 4822 276 13775 SWITCH L401 9965 000 14722 FIXED A 02 22µ TP 26MM
SW805 4822 276 13775 SWITCH L601 9965 000 14724 SPRING COIL 1.0µH K
SW806 4822 276 13775 SWITCH
SW807 4822 276 13775 SWITCH L605 9965 000 14724 SPRING COIL 1.0µH K
L701 9965 000 11379 FILTER MAINS 400µH
SW808 4822 276 13775 SWITCH L802 9965 000 14722 FIXED A 02 22µ TP 26MM
SW809 4822 276 13775 SWITCH L850 9965 000 14722 FIXED A 02 22µ TP 26MM
SW810 4822 276 13775 SWITCH T201 9965 000 11376 IND VAR 7MM 7PA 100KH Z B
SW811 4822 276 13775 SWITCH
SW812 4822 276 13775 SWITCH VR801 9965 000 14725 POTM CAR LIN 20K
X301 9965 000 14726 VIB XTAL 27MHZ 50PPM
SW813 4822 276 13775 SWITCH X401 9965 000 14542 8MHZ 467 CST8.46 MTW A
SW814 4822 276 13775 SWITCH X801 9965 000 14541 X-CRYSTAL 12M
T701 9965 000 14711 TRANSFORMER 127V/240V X901 9965 000 14727 CERA RESONATOR 1MHZ
9965 000 14712 MAINS CORD IEC
9965 000 14713 CONN ASSY 6P 2.0 235/315MM
9965 000 14714 CONN ASSY 6P 2.0 230 R PH
- DIODES -
9965 000 14715 FFC CABLE 1.0 100MM
9965 000 14716 FFC CABLE 1.0 70MM 6103 9965 000 11218 CHIP DIODE BAV99LT 1
9965 000 14717 CONN ASSY 2P 2.0 120 PH 6105 4822 130 83075 HN1V02H-B
9965 000 14718 FF-CABLE 16P CD-RF 6106 9340 255 30135 BAS216
!
!
!
!
!
!
!
!
!
