ELECTRICAL PARTS LIST - MAIN BOARD ELECTRICAL PARTS LIST - POWER BOARD
D103 994000005453 SCHOTTKY DIODE FM5819 C907 996500027125 COND DISC 0.0022UF 1KV 20%
D301 996510005666 DIODE CHIP BAV99 C908 996510005677 COND DISC 56pF 1KV 10%
IC101 996510005669 IC 128P SPHE8202L DVD C927
!
996500027115 CAP. SAFTY Y1 102PF 250V 20
%
IC103 996510005670 IC 50P EM636165TS-7G TSOP II D902 994000000941 DIODE HER104 1A 300V 50NS
IC104 996510005671 IC 8P EN25T80-75HCP EON D903 994000000941 DIODE HER104 1A 300V 50NS
IC107 994000005214 IC 28P V5888S D904 994000000941 DIODE HER104 1A 300V 50NS
IC401 996500029611 IC 8P CO4558A SO8 D909 994000001571 DIODE FR107 1A 1000V
JK401 996510005665 RCA JACK 4P WHT-NC/RED-YEL D910 994000005249 DIODE SB360 3A 60V DO-201AD
Q101 996510004117 FET 2SK3018 30V/0.1A SC-70 D912 996510004297 IN5819 1A 28V SCHOTTKY
Q102 996510004117 FET 2SK3018 30V/0.1A SC-70 F901
!
996510005675 FUSE T1.6A L250V 5x20mm
Q103 996500041293 XISTR NPN PMBT3904 GT903 996500029310 ABSORBER BL 140V 500A
Q104 996500026927 XISTR PNP 2SB1132RT100 ROHM IC901 996510005678 IC 8P TNY275PN 15W
Q105 996500026927 XISTR PNP 2SB1132RT100 ROHM IC902 994000000946 OPTICAL SENSOR 4P
Q106 996510005667 XISTR 8050S TO92 IC903 996500029312 IC 3 PIN TL431 TO-92
Q401 996500041293 XISTR NPN PMBT3904 L902 996500016694 6UH 13.5TS 2UEW
Q402 996500041293 XISTR NPN PMBT3904 NTC901 994000005232 THERMIST. NTC 5R 5A
Q406 996510005668 XISTR PNP 3906 SOT23 T901
!
996510005676 TRASFO EEL-19 5+7PIN
Q407 996510005668 XISTR PNP 3906 SOT23 TVR901 996500032754 THERMIST 50A 561V
Q901 996510000593 XISTR PNP 8550SS-D TO-92 CJ
Q902 996510000593 XISTR PNP 8550SS-D TO-92 CJ
RA101 996500041964 RES. ARRAY 4.7KR 1/16W 5%
Note: Only these parts mentioned in the list are
XL101 996500023929 X'TAL 27MHZ HC-49/US +/-15PPM
normal service parts.
ELECTRICAL PARTS LIST - VFD+KEY Boar
d
IC200A 996510005674 IC 44P PT6312BLQ PTC VFD
LD208A 996500012537 LED 3 DIA RED ROUND
SN200A 994000005472 IRT RECEIVER IRM-2638AF4
TA200A 996510005672 AI TACT SW H=5mm 160GF
TA201A 996510005672 AI TACT SW H=5mm 160GF
TA202A 996510005672 AI TACT SW H=5mm 160GF
TA203A 996510005672 AI TACT SW H=5mm 160GF
TA204A 996510005672 AI TACT SW H=5mm 160GF
TA205A 996510005672 AI TACT SW H=5mm 160GF
TA206A 996510005672 AI TACT SW H=5mm 160GF
TA207A 996510005672 AI TACT SW H=5mm 160GF
TA208A 996510005672 AI TACT SW H=5mm 160GF
TA209A 996510005672 AI TACT SW H=5mm 160GF
TA210A 996510005672 AI TACT SW H=5mm 160GF
TA211A 996510005672 AI TACT SW H=5mm 160GF
TA212A 996510005672 AI TACT SW H=5mm 160GF
TA213A 996510005672 AI TACT SW H=5mm 160GF
VFD200A 996510005673 VFD 27P L65xW20xT6.1
