8 - 4
FACTORY MECHANICAL PART LIST (ONLY FOR REFERENCE)
Loc. Part NO. Description
1 BPB100040-0004 BTM CAB HIPS 94HB
2 GSE100763-0001 POWER BKT-LOW
3 APE303790-0005 POWER PCB ASS’Y
4 GSE100764-0001 POWER BKT-HIGH
5 APE107410-0001 MAIN BOARD
6 GTP100193-0001 EMC SCREEN COVER
7 BFP121128-0001 DUST PVC SHEET
8 GSE100632-0001 MICRO SW BKT
9 MSW002005-0010 SW LEAF
10 ASL261606-1106 TRAVERSE
11 LUC107423-0201 GEAR SUPPRESS PCB
12 DGD101003-0001 DUMP GEAR
13 BPC100076-0201 TOP CAB
14 DDL100001-2001 DOOR LOCK
15 DBU001001-0020 AC LINE BUSHING
16 GSW100007-0001 DOOR SPRING
17 GSE100655-0001 DOOR BKT
18 BPD101124-0001 CD DOOR
19 BPN100282-0001 DOOR LENS
20 BPK102108-0001 FUNCTION BUTTON
21 APE107422-0001 KEY PCB ASS’Y
22 APE107420-0001 VFD=KEY PCB ASS’Y
23 IVE100397-0001 VFD SPONGE
24 IVE100377-0002 IR SPONGE
25 RHO263804-2102 IRT RECEIVER
26 BPN100283-0001 STANDBY LENS
27 BPK112108-0001 POWER KNOB
28 KLV000050-0010 VFD 27P
29 BPK122108-0001 PLAY BUTTON
30 BPK132108-0002 STOP BUTTON
31 BPK142108-0001 VOL BUTTON
32 BPF106061-3002 FRONT PANEL
33 BPY100015-0001 RING
34 BPN100281-0012 DISPLAY LENS
S1 HST140054-1120 SCREW
S2 HSW140054-1080 SCREW
S3 HSP140054-1080 SCREW
S4 HST143084-1060 SCREW
S5 HSW140054-1081 SCREW
S6 HSP140044-1040 SCREW
S7 HSW140044-1060 SCREW
