Philips MCD708 - Page 36

13 - 2
ELECTRICAL PARTS LIST - AMP PART
- IC -
IC303 9940 000 03423 IC TDA8922BTH
IC304 9940 000 03423 IC TDA8922BTH
IC305 9940 000 03424 IC 74HCU04D
IC306 9940 000 03425 IC HEF4013T
IC4 9940 000 03426 IC PT2323
IC7 9940 000 03428 IC PT2322
IC8 9940 000 03429 IC 4558
- COILS & FILTERS -
XT301 9940 000 03453 CER.FILTER CRB 700KHz
XT302 9940 000 03454 CER. FILTER FREQ. 600KHz
CF2 9940 000 03153 CER. FILTER FREQ. 600KHz
CF1 9940 000 03153 CER. FILTER FREQ. 600KHz
CF1 996500038464 AM FILTER 10.7 TDK (for -/37)
CF2 996500038464 AM FILTER 10.7 TDK (for -/37)
CF4 996500038464 AM FILTER 10.7 TDK (for -/37)
T1 994000005141 I.F.T. COIL BLACK 6298
T2 994000005139 I.F.T. COIL YELLOW 6297
T3 994000005139 I.F.T. COIL YELLOW 6297
T4 994000005142 I.F.T. COIL BLACK 6299
T5 994000005138 I.F.T. COIL BROWN 6296
T7 994000005137 I.F.T. COIL BLACK 6295
- MISCELLANEOUS -
X1 9940 000 03452 QUARTZ CRYSTAL 75KHz Φ3.0
JACK1 9940 000 02528 4PINS RCA SOCKET
ENCODER801 9940 000 02535 VOLUME CODER ED-1612-00-F15
S1 9940 000 02542 IR SENSOR
SPK1 9940 000 03431 5.1 SPEAKER JACK 6PZ-1
SW901 9940 000 03432 LIGHT TOUCH SWITCH
F301
!
9940 000 03433 FUSE F6.3AL250V
F302
!
9940 000 03433 FUSE F6.3AL250V
CN10 9940 000 03434 PIN CONNECTOR 40PINS 90°
JACK1 9940 000 03435 ANT. LEADING-OUT JACK
9965 000 38467 TRANSFORMER ECO 120V/60(for -/37)
9965 000 38465 ECO6-02 TUNER PCB ASS'Y(for -/37/12)
9940 000 05317 ECO6-01 TUNER PCB ASS'Y(for -/58/93/98/79)
9965 000 38466 AMP PCB ASS'Y(not for -/12)
9965 000 39006 AMP PCB ASS'Y(for -/12)
Note: Only these parts mentioned in the list are
normal service parts.
