13 - 3
ELECTRICAL PARTS LIST - DVD PART
- DIODES -
BD201 9940 000 02521 THYRISTOR RS406
D210 9940 000 02544 RECTIFIER DIODE IN5822
DZ201 9940 000 03407 ZENER DIODE 3.3V
DZ202 9940 000 03408 ZENER DIODE 27V
LED601 9940 000 02537 LED LAMP 3R4CB71D-2B-208 (for -/12)
- TRANSISTORS -
Q201 9940 000 02519 TRANSISTOR 8550C
Q202 9940 000 02519 TRANSISTOR 8550C
Q206 9940 000 02519 TRANSISTOR 8550C
Q208 9940 000 02519 TRANSISTOR 8550C
Q203 9940 000 02518 TRANSISTOR 8050C
Q204 9940 000 02518 TRANSISTOR 8050C
Q207 9940 000 02518 TRANSISTOR 8050C
Q209 9940 000 02518 TRANSISTOR 8050C
Q210 9940 000 02518 TRANSISTOR 8050C
Q205 9940 000 02545 TRRANSISTOR 9014C
Q2201 9940 000 02518 TRANSISTOR 8050C (for -/12)
- IC -
IC202 9940 000 02547 IC AT24C02-PC27
IC203
9965 000 40191 CPU U252 (for -/37)
IC203
9965 000 40189 CPU U252 (for -/12)
IC203
9965 000 40193 CPU U252 (for -/58)
IC203 9965 000 40195 CPU U252 (for -/79)
IC203 9965 000 40197 CPU U252 (for -/93)
IC203 9965 000 40199 CPU U252 (for -/98)
IC204 9940 000 03978
IC PT2579-SN SMALL(for -/12)
IC205 9940 000 03411 IC D4558/RC4558
IC207 9940 000 02548 IC LM7805/LM340T5 7805
IC209 9940 000 02548
IC LM7805/LM340T5 7805 (for -/37)
IC208 9940 000 02546 IC YD2576-ADJ
IC601 9940 000 02539 IC PT6311 / SC16311 / CD16311
IC201 9940 000 03512 CHIP IC AC6811(for -/12)
- MISCELLANEOUS -
X201 9940 000 03152 CERMIC FILTER FREQ. 4.19MHZ
X202 9940 000 02551 CRYSTAL OSC FREQ.32.768 KHz
X203 9940 000 04962
CRYSTAL 4.3320Hz (for -/12)
F201
!
9940 000 02529 FUSE F2AL250V
F209
!
9940 000 03412 FUSE F1.5A/125V
