ELECTRICAL PARTSLIST
V
FD DISPLAY BOARD ASSEMBLY
B200
!
996510002975 TRANSFORMER EE13 5V
D208 996510002976 DIODE FR104
DZ200 996510006505 ZENER DIODE 6.2V 1W
IC203 996510000500 IC PT6311/SC16311/CD16311
LED200 994000004948 LED LAMP(BLUE)
S1 996510010498 IR SENSOR BRACKET
S200 994000004961 IR SENSOR BLACK
SW200 996510000020 LIGHT TOUCH SW.
SW202 996510000263 LIGHT TOUCH SWITCH 6X6X5
VFD200 996510002921 VFD DISPLAY NE-705D-3.GB
CN100 996510000228 RCA SOCKET 2p AV2-8.4-13 RD WH
J1501 996510010544 SOCKET 21PINS CS-106 1501D6
Note: Only these parts mentioned in the list are
normal service parts.
