ELECTRICAL PARTSLIST - DVD PART
- MISCELLANEOUS -
SW401 9940 000 02536 SPECIAL SWITCH TC-V030A
SW402 9940 000 02536 SPECIAL SWITCH TC-V030A
SW1201 9940 000 02555 LIGHT TOUCH SWITCH
SW1202 9940 000 02555 LIGHT TOUCH SWITCH
SW1203 9940 000 02555 LIGHT TOUCH SWITCH
SW1204 9940 000 02555 LIGHT TOUCH SWITCH
SW706 9940 000 02557 SWITCH(4-DIRECTIONS)
9940 000 02541 VFD DISPLAY NE-700D-3.WR
S701 9940 000 02542 IR SENSOR
SW701 9940 000 02543 LIGHT TOUCH SWITCH
X1 9940 000 02551 CRYSTAL OSC FREQ. 32.768 KHZ
X1 9940 000 03452 QUARTZ CRYSTAL 75KHZ D3.0
X2 9940 000 03152 CERMIC FILTER FREQUENCY 4.19MHz
CN7 9965 000 41002 SPEAKER SOCKET DJ-270-DH-03
CN5 9965 000 41002 SPEAKER SOCKET DJ-270-DH-03
F101 9940 000 02529 FUSE F2AL250V
JP818 9940 000 03412 FUSE F1.5A/125V (for -/93)
JP818 9965 000 42106 FUSE F1.5A/125V (for -/98)
JK1501 9965 000 42013 ANT. LEADING-OUT TERMINAL
9940 000 05068 DOOR SWITCH
9940 000 02487 WORM & WORM WHEEL BRACKET
JAK501 9965 000 42015 6P RCA SOCKET
JAK503 9940 000 04982 S-VIDEO OUTPUT SOCKET
JAK502 9940 000 04944 AV OUT SOCKET 4P
9965 000 42018 EC06-01 TUNER PCB ASS'Y
9965 000 42019 CPU PCB ASS'Y MCD735/93/98
9965 000 41028 DVD BRICK ASSY MCD735/37
- DIODES -
D1 9940 000 03764 DIODE BAV99
D2 9940 000 03759 DIODE BAS316
DZ1 9940 000 03761 ZENER DIODE BZX384-C11 11V
D3 9940 000 03762 VARIODE DIODE I348
D4 9940 000 03763 VARIODE DIODE BB804
D5 9940 000 03763 VARIODE DIODE BB804
D3 9940 000 03714 DIODE IN60 L=52MM
D5 9940 000 03714 DIODE IN60 L=52MM
D7 9940 000 02544 RECTIFIER DIODE IN5822
BD1 9940 000 02521 THYRISTOR RS406(4A)
LED1 9940 000 02537 LED (BLUE) 3R4CB71D-2B-208
LED701 9940 000 05215 LED DIODE RED
- COILS & FILTERS -
T7 9940 000 05137 I.F.T. COIL BROWN 6295
T5 9940 000 05138 I.F.T. COIL BROWN 6296
T2 9940 000 05139 I.F.T. COIL BROWN 6298
T3 9940 000 05139 I.F.T. COIL BROWN 6298
T1 9940 000 05141 I.F.T. COIL BROWN 6298
T4 9940 000 05142 I.F.T. COIL BROWN 6299
CF2 9940 000 03153 FM CER. FILTER FREQUENCY 10.7MHz
CF1 9940 000 03153 FM CER. FILTER FREQUENCY 10.7MHz
!
!
!
