ELECTRICAL PARTSLIST - AMP PART
- MISCELLANEOUS -
SPK1 9940 000 03431 5.1 SPEAKER JACK 6PZ-1
F202 9940 000 02531 FUSE F4AL250V
F203 9940 000 02531 FUSE F4AL250V
COD301 9940 000 02535 VOLUME CODER ED-1612-00-F15
J1100 9940 000 02534 HEADPHONE JACK 3.5MM
9965 000 42021 TRANSFORMER 417D6-93 220V/50 (for -/93)
9965 000 42107 TRANSFORMER 417D6-98 120V/230V (for -/98)
9965 000 42022 AMP PCB ASS'Y MCD735/93
9965 000 41029 AMP BIRCK ASSY MCD735/37
- DIODES -
ZD107 9940 000 02515 ZENER DIODE 3V
D101 9940 000 03502 THYRISTOR RS808
D201 9940 000 03714 DIODE IN60 L=52MM
ZD201 9940 000 03417 ZENER DIODE 5.6V
- IC & TRANSISTORS -
Q101 9940 000 02517 TRANSISTOR 2SB772
Q204 9940 000 02518 TRANSISTOR 8050C
Q205 9940 000 02519 TRANSISTOR 8550C
IC205 9940 000 04669 IC TL072
IC201 9940 000 04976 IC TDA7264
IC202 9940 000 04976 IC TDA7264
IC203 9940 000 04976 IC TDA7264
IC204 9940 000 02524 IC PT2309-S(L)
IC206 9940 000 04937 IC 7812
IC1301 9940 000 03767 IC TDA7265 STEREO POWER IC
Note: Only these parts mentioned in the list are
normal service parts.
!
!
!
!
