In standby mode, press and hold CLOCK on the remote control.
When the hour digits ß ash, turn VOLUME on the system or press VOL+/- on the remote
control to set the hours.
Press
CLOCK again and the minute digits ß ash. Then turn VOLUME on the system or press
VOL+/- on the remote control to set the minutes.
Press
CLOCK again to conÞ rm the time setting.
1
2
3
Speaker
(right)
Speaker
(left)
FM antenna
AC power
Setting the clock
IMPORTANT!
– To set clock in the Eco Power mode, press and hold STANDBY-ON
2
on the set for 3 seconds or more to switch to normal
standby mode Þ rst before proceeding with the procedures below.
Tip
See the User Manual for how to connect
other equipment to this system.
4
Connect the speaker cables.
Connect the control cable.
Connect the FM antenna.
Connect the power cord of the system.
1
2
3
4
