Philips MX5100VR/00 - LOCATION OF CBAS (PC BOARDS)

1-7-1 E9015LOC
Front CBA
DVD Main CBA Unit
Sensor CBA
DVD OPEN/CLOSE CBA
Main CBA
Sensor CBA
Tuner CBA
AFV CBA
AM/FM Tuner Unit
Power Supply (Audio Module) board
Power Amplifier board
AF board
Speaker Connector board
Power Supply (For VCR/DVD) CBA
Junction-C CBA
L
ED CBA
Jack-A CB
A
Junction-A CBA
Junction-B CBA
Jack-B CBA
Jack C CBA
DAC CBA
LOCATION OF CBAS (PC BOARDS)
