Main 8/11 Schematic Diagram Parts Location Guide
1-12-23
Ref No. Position Ref No. Position
C2004 AQ-1 R653 AM-2
C2008 AO-3 R654 AM-1
C2009 AO-3 R655 AM-1
C2012 AQ-1 R2005 AQ-1
C2013 AN-1 R2022 AN-3
C2014 AN-1 R2027 AO-3
C2015 AN-1 R2038 AO-4
R2039 AO-4
CL2015 AN-4 R2040 AO-4
CN2001 AM-2 R2047 AO-4
CN2020 AM-1 R2094 AP-1
R2103 AO-3
D2009 AO-3 R2104 AN-3
R2105 AO-2
IC1404 AF-3 R2106 AO-2
IC2002 AO-3 R2107 AO-2
R2113 AN-1
L2001 AP-1 R2114 AN-1
L2002 AN-1
L2007 AN-1 SW2021 AO-2
L2008 AN-1 SW2022 AO-2
Q516 AN-2 X2001 AP-3
Q1505 AN-2
Q1506 AP-2 JK1405 AN-1
Q2007 AO-4 RM2001 AQ-1
R592 AM-2
COILS
ICS
CAPACITORS
DIODE
RESISTORS
CONNECTORS
SWITCHES
CRYSTAL OSCILLATOR
MISCELLANEOUS
RESISTORS
TRANSISTORS
