Choosing a Report Format
PageWriter 100 M1772A Cardiograph 2-13
2
&KRRVLQJD5HSRUW)RUPDW
An Auto report prints a one-page (at 25 mm/sec) or two-page (at 50
mm/sec) summary of all 12 ECG leads. A Manual report presents a
continuous printout of the selected lead group until the key is
pressed.
$XWR5HSRUW)RUPDW
The Auto report format is a standard 12-lead ECG with a lead II rhythm
strip. Figure 2-2 is an example of the auto report format.
0DQXDO5HSRUW)RUPDWV
Manual ECGs reflect the ECG waveform as it occurs and there is no
significant delay in the recording.
Alternate lead groups can be selected while recording a 3- or 6-lead
ECG by pressing until the light above the desired lead group is lit.
The following table shows the available lead group choices. The
following list shows the available lead-group configurations.
7DEOH0DQXDO/HDG*URXSV
Number of
Leads
Light on
(from left)
Lead Groups
Leftmost I, II, III
3 2nd aVR, aVL, aVF
3rd II, aVF, V2
6 Rightmost V1, V2, V3, V4, V5, V6
6WRS

