15EN
Connect the second screen
Caution
Turn off your player before you connect the second screen.
A: main unit; B: second screen
1 Connect the supplied AV cable to:
the AV OUT jack on the main unit.
the AV IN jack on the second screen.
Connect power
Connect power through car adaptor
Caution
Risk of product damage! Ensure that the power supply voltage corresponds to the voltage pointed
on the back or the underside of the player.
Risk of electric shock! When you unplug the AC adaptor, always pull the plug from the socket.
Never pull the cable.
English
PD7022_12_UM_Book1_V3.1.indb 15 7/30/2012 3:45:20 PM
