22 EN
7 Product information
Note
• Product information is subject to change without prior notice.
Dimensions
- Main unit
- Second screen
200 x 155 x 39 mm
200 x 155 x 21 mm
Weight
- Main unit
- Second screen
0.7 kg
0.4 kg
AC Power adaptor ASUC12E-090080 (Philips)
Power supply Input: 100-240V 50/60Hz 0.3A
Output: DC 9V 0.8A
Power consumption 9 W
Operating temperature range 0-45°C
Laser wavelength 650 nm
Video system NTSC & PAL
Frequency response 20Hz-20KHz ± 1dB
Signal/noise ratio
80 dB
Audio distortion + noise
-80 (1KHz)
Channel separation
80 dB
Dynamic range
80 dB
Audio out (analog audio) Output level: 2V ± 10%
Load impedance
10 K
Video out Output level: 1Vp - p ± 20%
Load impedance
75
PD7022_12_UM_Book1_V3.1.indb 22 7/30/2012 3:45:24 PM
