HD3610/50
8-12
TROUBLE SHOOTING
Problem Cause Repair solution
6 Beer leakage. 1. Leakage spout side.
2. Leakage on top of the Keg.
1. Check beer tube on hairline cracks or check
closing mechanism tap unit.
2. Check beer tube, tap unit and Keg.
7 Condensation water
leakage.
Through the cooling process condensation
water is formed and can drip under the
appliance.
1. Check if doors were closed properly. (If not
closed extra condensation will be build)
2. Check if the drip tray was well placed.
8 No foam on the Beer. Check the following conditions. 1. Temperature of the Beer must be below 9 °C.
2. Glasses have to be clean.
3. Beer tube connector is not properly installed
or is damaged.
Check DFU for more tips.
9 To much foam Check the following conditions. 1. Temperature of the Beer must be below 9 °C.
2. Beer tube connector is not properly installed
or is damaged.
3. Check if there is no air leakage in the system.
4. When the keg is almost empty it is possible
that only foam will come out.
Check DFU for more tips.
PARTS LIST
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
11
12*
13
14
15
16
17
18
19
20
21
22
23
24*
4222 459 45199
4222 459 45212
4222 459 45149
9965 000 44304
9965 000 26126
9965 000 32659
9965 000 26121
9965 000 26122
4222 459 45213
9965 000 26124
9965 000 26123
4222 459 45215
4222 459 45216
9965 000 44309
9965 000 26117
9965 000 26115
9965 000 26116
9965 000 44310
9965 000 26111
4222 459 45214
9965 000 32874
9965 000 26110
9965 000 26109
9965 000 26119
Rear case assy
Right Door assy
Left Door assy
Connector/Lever assy
O-ring 11X2 Air inlet side
O-ring
Handle assy
Handle O-ring
Tap unit (without taphandle)
Spout O-ring
Spout
Plastic plate driptray top
Baseplate Driptray
NTC sensor assy
Pressure sensor PCB
Grommet. Pump position
Pump assy including pressure sensor
Power supply HV 220 - 240 V
Micro switch assy
Main PCB + 3 LED PCB
Drop ring
Grommet, FAN position
Fan assy
Peltier assy
* Standardised part
