X-deflection
Source
Ya-input;
Time
base
Frequency
range
DC:
0...2MHz
(-3
cB)
Phase
shift
3°
at
10
kHz
Power
supply
Double
insulated
Nominal
voltage
range
110;
220
or
240
Vac
+
10%
Nominal
frequency
range
46
...66Hz
Power
consumption
25
W
(30
VA)
max.
Mechanical data
Length
370
mm
incl.
controls
(450
mm
incl.
handle)
Width
297
mm
excl.
handle
(330
mm
incl.
handle)
Height
129
mm
excl.
feet
(138
mm
incl.
feet)
Weight
46
N
(4.7
kg)
OPTIONAL ACCESSORIES
PM
9326
Passive
probe
1:1/10:1;1,1.m
PM
9327
Passive
probe
1:
1/10:1;2,1m
PM
9328
Set
of
two
passive
probes
1:1/10:1
PM
8921
(L)
Passive
probe
1:
1;
1,5
m
(2,5
m)
PM
8925
(L)
Passive
probe
10:
1;
11
pF;
1,5
m
(14
pF;
2,5
m)
PM
8932
Passive
probe
100
:
1;
max.
voltage
2000
V;
1,2
pF;1,5m
PM
9355
Current
probe;
12
Hz
...
70
MHz
PM 9366 Collapsible viewing hood
PM
8980
Closed,
tong
type
viewing
hood
DIRECTIONS FOR USE
Safety
regulations
(in
accordance
with
|EC
348)
Before
connecting
the
instrument
to
the
mains
(line),
visually
check
the
cabinet,
controls
and
connectors
etc.,
to
ascertain
that
no
damage
has
occurred
in
transit.
If
any
defects
are
apparent,
do
not
connect
instrument
to
the
mains
(line).
The
instrument
must
be
dis-
connected
from
all
voltage
sources,
and
any
high
voltage
points
discharged
before
any
maintenance
or
repair
work
is
carried
out.
If
adjustments
or
maintenance
of
the
operating
instrument
with
covers
removed
is
inevitable,
it
must
be
carried
out
only
by
a
skilled
person
who
is
aware
of
the
hazards
involved.
In
normal
Operation
the
double-insulated
power
supply
obviates
the
need
of
a
safety
ground.
WARNING:
IT
MUST
BE
BORNE
IN
MIND
THAT
IN
ALL
MEASUREMENTS
THE
FRAME
GROUND
OF
THE
OSCILLOSCOPE
IS
RAISED
TO
THE
SAME
POTENTIAL
AS
THAT
OF
THE
MEASURING
GROUND
PROBE
CONNECTION.
NEITHER
THE
PROBE’S
GROUND
LEAD
NOR
THE
FRAME
GROUND
SHALL
BE
CONNECTED
TO
LIVE
POTENTIALS.
