Philips VR140/02 - Page 34

Ref No. Position Ref No. Position Ref No. Position Ref No. Position Ref No. Position Ref No. Position
C002 G-3 C326 D-2 C451 B-3 C529 D-1 CL504 E-3 L003 F-3
C003 F-3 C327 D-2 C452 C-3 C530 D-1 CL508 B-1 L009 G-1
C004 G-3 C328 D-2 C453 C-3 C531 C-1 CL510 F-1 L010 G-1
C005 G-2 C329 D-2 C454 B-3 C532 E-1 CN701 A-1 L012 F-1
C006 G-2 C330 D-2 C455 C-3 C533 D-1 L251 C-3
C007 G-2 C332 C-2 C456 C-3 C535 D-2 D001 G-3 L301 C-3
C008 G-2 C333 C-2 C457 C-3 C538 B-3 D002 G-3 L370 E-3
C010 G-3 C334 C-3 C458 C-3 C540 E-1 D003 G-3 L402 E-3
C011 F-2 C335 C-2 C459 C-3 C561 E-1 D004 G-3 L403 F-3
C012 F-2 C336 D-1 C460 C-3 C562 E-1 D005 G-2 L451 C-3
C014 F-1 C337 C-3 C461 C-3 C563 D006 G-2 L452 C-2
C017 G-2 C338 C-3 C462 C-3 C564 E-3 D007 F-2 L501 E-1
C018 G-1 C339 C-3 C463 C-3 C621 E-2 D008 F-2 L561 E-1
C020 G-2 C340 C-3 C464 C-3 C622 D-1 D009 G-3 L562 E-1
C021 G-1 C341 C-3 C465 C-3 C640 B-1 D011 G-2 L701 A-3
C022 F-2 C342 C-3 C466 C-2 C642 B-1 D012 G-2 L702 A-1
C025 F-2 C343 C-3 C467 C-2 C643 B-1 D013 G-2 L703 A-1
C026 F-1 C345 D-2 C468 C-2 C644 B-1 D014 G-2 L704 A-2
C053 F-1 C346 C-2 C469 C-2 C645 B-1 D015 G-1 L851 C-1
C056G-1C347C-3C470C-2C648B-1D016F-2
C057F-1C351C-2C471C-2C649B-1D018G-2Q001G-2
C060 F-1 C352 D-2 C472 C-3 C701 A-3 D019 F-2 Q002 G-2
C061 F-1 C370 D-3 C473 C-2 C702 A-3 D021 F-2 Q003 G-3
C151 B-2 C371 E-2 C474 C-2 C703 A-3 D023 F-2 Q004 F-2
C152 B-2 C372 E-2 C475 B-2 C704 A-2 D051 F-1 Q051 F-2
C153 B-2 C373 E-2 C476 C-2 C706 A-2 D052 F-2 Q052 F-2
C154 B-2 C374 E-3 C477 B-2 C707 A-1 D053 F-1 Q053 F-1
C155 B-2 C375 E-3 C478 B-2 C708 A-1 D055 A-1 Q054 F-1
C156 C-2 C376 E-3 C479 B-3 C709 A-1 D056 G-2 Q055 F-1
C157 A-3 C377 E-2 C480 C-2 C710 A-1 D057 F-1 Q056 F-1
C158 A-3 C378 E-3 C481 B-3 C712 A-1 D058 F-2 Q057 G-2
C159 C-2 C379 E-3 C482 B-3 C715 A-1 D153 A-3 Q058 G-1
C251 C-3 C381 E-3 C483 B-3 C716 A-1 D154 A-3 Q059 F-1
C252 C-3 C382 E-3 C484 B-3 C717 A-1 D155 A-3 Q151 B-2
C253 C-3 C383 E-3 C485 C-3 C756 A-1 D156 A-2 Q152 C-2
C254 C-3 C384 E-3 C486 C-3 C757 A-1 D157 A-3 Q153 A-3
C302 D-3 C401 E-3 C489 B-2 C771 E-2 D301 C-3 Q351 C-2
C303 D-3 C402 F-3 C501 D-1 C772 F-2 D370 E-3 Q352 D-3
C304 D-3 C403 F-3 C502 D-1 C773 E-2 D501 D-1 Q401 F-3
C305 D-3 C404 F-3 C506 C-1 C774 E-2 D502 D-2 Q402 F-3
C307 D-3 C411 D-3 C508 C-1 C775 E-2 D552 C-2 Q403 E-3
C308 D-3 C412 D-3 C510 C-1 C776 E-2 D553 C-2 Q405 E-3
C309 D-3 C414 D-3 C511 C-1 C777 E-2 D621 D-1 Q406 D-3
C310 D-3 C415 D-3 C512 C-1 C778 E-2 D701 A-2 Q451 C-3
C311 D-3 C416 D-3 C513 C-1 C851 C-1 Q501 C-1
C312D-3C417D-3C514C-1C852C-2IC001F-2Q502D-1
C313D-2C418D-3C515C-1C853D-2IC151B-2Q503D-2
C314 D-3 C419 B-3 C516 C-2 C854 C-2 IC301 D-3 Q504 F-3
C315D-3C421D-3C517E-1C855D-2IC370E-3Q505B-3
C316D-3C422D-3C518E-1C856D-1IC451C-3Q551C-2
C317D-2C423D-3C519E-1C858D-2IC501D-1Q552C-1
C318D-2C424D-3C520D-1C859C-1IC503E-2Q621E-2
C319 D-2 C425 D-3 C521 D-1 C862 D-2 IC561 E-1 Q771 F-2
C320 D-2 C426 D-3 C522 D-1 IC640 B-1 Q772 F-2
C321 D-2 C427 D-3 C523 E-1 CL151 B-3 IC771 E-2
C322 D-2 C428 E-3 C524 D-1 CL152 A-2 R001 F-3
C323 D-2 C429 D-3 C526 E-1 CL253 C-3 J902 F-3 R002 G-2
C324 D-2 C430 C-3 C527 D-1 CL501 B-3 L001 G-3 R003 G-2
C325 D-2 C431 D-3 C528 D-1 CL502 E-2 L002 F-3 R004 G-2
RESISTORS
ICS
COILS
TRANSISTORS
CAPACITORS CAPACITORS CAPACITORS CAPACITORS
CONNECTORS
CONNECTORS COILS
DIODES
Ref No. Position Ref No. Position Ref No. Position Ref No. Position Ref No. Position
R005 G-2 R314 C-3 R456 B-3 R539 F-1 R784 E-2
R006 G-2 R315 C-3 R457 B-3 R540 C-1 R785 E-2
R007 G-2 R316 C-3 R458 B-3 R541 C-1 R786 E-2
R008 G-2 R317 C-3 R459 B-3 R542 B-1 R787 E-2
R009 F-2 R318 C-3 R460 C-3 R543 B-1 R851 C-2
R011 G-2 R319 C-3 R461 C-3 R544 C-1 R852 C-2
R012 G-2 R320 C-3 R462 C-3 R545 E-1 R853 D-2
R013 G-3 R321 D-2 R463 C-2 R546 F-1
R014 G-2 R322 D-2 R464 C-2 R547 F-1 SW501 B-1
R015 G-3 R323 D-2 R465 C-2 R548 F-1 SW502 B-1
R016 G-3 R324 C-3 R466 C-2 R549 G-1 SW503 B-1
R017 F-2 R325 D-2 R467 B-2 R551 C-2 SW505 E-1
R018 F-2 R326 D-2 R468 C-2 R552 C-2 SW506 C-1
R021 F-2 R330 D-2 R469 C-2 R555 C-1 SW507 F-2
R022 F-2 R331 D-3 R470 B-2 R556 C-1 SW509 F-1
R023 F-2 R332 D-2 R471 C-2 R557 C-1 SW510 F-1
R024 F-2 R333 C-2 R472 B-2 R558 C-1 SW511 F-1
R025 F-2 R334 D-2 R473 B-2 R566 E-1 SW512 G-1
R026 G-1 R351 C-2 R474 B-2 R571 B-3
R027 F-2 R352 C-2 R475 B-3 R604 D-1 VR501 A-1
R028 G-2 R355 C-2 R476 B-3 R609 C-1
R029 F-2 R357 C-2 R477 B-3 R610 C-1 X301 D-3
R054 F-1 R358 C-2 R478 C-3 R611 C-1 X501 C-1
R058 F-1 R360 D-3 R479 C-3 R617 C-1 X502 C-1
R059 G-1 R361 D-2 R480 B-3 R618 C-1
R060 G-1 R370 E-2 R481 B-3 R619 C-1 AC001 F-3
R061 G-1 R371 E-3 R501 C-1 R621 D-2 F001 G-3
R062 F-1 R372 E-3 R502 C-1 R622 D-2 FP562 D-1
R063 F-1 R401 D-3 R503 C-1 R623 E-2 JK756 A-1
R064 F-1 R402 F-3 R504 C-1 R624 D-1 JK757 A-1
R065 F-1 R403 F-3 R505 C-1 R625 D-1 JK758 A-1
R066 F-2 R404 F-3 R506 C-1 R638 B-1 PS503 C-2
R067 F-1 R407 D-3 R508 B-1 R641 B-1 RS501 C-1
R068 F-1 R408 C-3 R509 C-1 R642 B-1 SA001 F-3
R069 F-2 R409 C-3 R510 D-1 R643 B-1 T001 F-2
R070 F-2 R411 C-3 R511 C-1 R644 B-1 TU701 A-3
R071 F-1 R412 D-3 R513 C-2 R645 B-1
R072 F-2 R413 D-3 R514 C-2 R701 A-2 J23 A-2
R073 G-1 R414 D-3 R516 C-1 R702 B-1 TP301 G-1
R151 B-2 R415 D-3 R517 C-1 R703 B-1 TP501 G-1
R152 B-2 R416 D-3 R518 C-2 R704 B-1 TP502 A-1
R153 C-2 R417 D-3 R520 E-1 R706 A-1 TP506 A-1
R154 C-2 R418 D-3 R521 E-1 R756 A-1 TP507 G-1
R155 B-2 R421 D-3 R522 E-1 R757 A-1
R158 B-3 R422 D-3 R523 D-2 R758 A-1
R251 C-3 R423 B-3 R524 E-2 R759 A-1
R252 C-3 R424 D-3 R525 D-2 R771 E-2
R301 D-3 R425 E-3 R526 E-1 R772 E-2
R302 D-3 R426 E-3 R527 E-1 R773 E-2
R303 D-3 R427 E-3 R528 A-1 R774 E-2
R304 D-3 R428 E-3 R529 D-2 R775 E-2
R305 D-3 R429 D-3 R530 C-2 R776 F-2
R307 C-2 R430 D-3 R531 C-1 R777 F-2
R308 C-2 R431 E-3 R533 E-1 R778 E-2
R309 C-3 R451 C-3 R534 F-2 R779 E-2
R310 C-1 R452 B-3 R535 F-2 R780 E-2
R311 C-1 R453 C-3 R536 F-2 R781 E-2
R312 C-2 R454 B-3 R537 F-2 R782 E-2
R313 C-2 R455 B-3 R538 E-2 R783 E-2
RESISTORS
TEST POINTS
CRYSTAL OSCILLATOR
S
SWITCHES
MISCELLANEOUS
VARIABLE RESISTORS
RESISTORSRESISTORS RESISTORSRESISTORS
Main CBA Parts Location Guide
1-10-54
1-10-55
